Home
Attachments & Lift
Hydraulic Systems
Hoses & Fittings
Alfagomma - FMUB3024 - Swivel 1-7/8 JIC X 1/2 BSP
Alfagomma - FMUB3024 - Swivel 1-7/8 JIC X 1/2 BSP
Alfagomma - FMUB3024 - Swivel 1-7/8 JIC X 1/2 BSP
Alfagomma - FMUB3024 - Swivel 1-7/8 JIC X 1/2 BSP

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping on orders over €60

Pay Securely with

Alfagomma - FMUB3024 - Swivel 1-7/8 JIC X 1/2 BSP

Alfagomma - FMUB3024 - Swivel 1-7/8 JIC X 1/2 BSP

€23.20

(Excl. VAT)

Price

(Excl. VAT)

€23.20

Alfagomma
Alfagomma produces hydraulic hoses, couplings, and fittings for agricultural and industrial machinery. The brand's products are used in tractors, irrigation systems, and hydraulic-powered farm equipment. Its solutions ensure leak-free connections and high-pressure resistance in demanding farming applications. Shop more than 2,415 genuine Alfagomma spare parts.

Product Details

Brand
Alfagomma
Unit
Each
Shape
Straight - 2 connection sides
Length
76 mm
Material
Steel
Cone angle
74 °
Surface treatment
Galvanised
Connection 2, type
Thread
Connection no 1 type
Swivel nut
Max working pressure
180 BAR
LConnection no 1 length
38 mm
Connection 2, thread length
19,5 mm
F2Connection 2, thread type
BSP
F1Connection no 1 thread type
JIC
Connection 2, threads per inch
11
F2Connection 2, thread diameter
1-1/2 Inch
Connection 2, type - male/female
Male
Connection no 1 threads per inch
12
F1Connection no 1 thread diameter
1-7/8 Inch
Connection no 1 type - male/female
Female
Manufacturer
Alfagomma
