Alfagomma - SFSNS201645 - Insert NS-DN20+Flange Diameter 47.6
Alfagomma - SFSNS201645 - Insert NS-DN20+Flange Diameter 47.6
Alfagomma - SFSNS201645 - Insert NS-DN20+Flange Diameter 47.6
Alfagomma - SFSNS201645 - Insert NS-DN20+Flange Diameter 47.6

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping on orders over €60

Pay Securely with

Alfagomma - SFSNS201645 - Insert NS-DN20+Flange Diameter 47.6

Alfagomma - SFSNS201645 - Insert NS-DN20+Flange Diameter 47.6

€22.46

(Excl. VAT)

Price

(Excl. VAT)

€22.46

Product Description

The Alfagomma No-Skive press fitting is used in combination with Alfabiotech high-pressure hoses. With these press fittings, there is no need to skive the inner and outer casing.
Alfagomma
Alfagomma produces hydraulic hoses, couplings, and fittings for agricultural and industrial machinery. The brand's products are used in tractors, irrigation systems, and hydraulic-powered farm equipment. Its solutions ensure leak-free connections and high-pressure resistance in demanding farming applications. Shop more than 2,415 genuine Alfagomma spare parts.

Product Details

Brand
Alfagomma
Pros
Press fittings help ensure faster and easier hose assembly and help to save costs. Processing produces less dirt, smell and waste. No special tool needed to skive the hose.
Unit
Each
Angle
45 °
Shape
Elbow - 2 connection sides
Connection 2, type
Hose end
Connection no 1 type
Flange
Max working pressure
415 BAR
Connection 2, diameter
20 mm
FDConnection no 1 diameter
47,6 mm
Flange standard pressure series
6000
Connection 2, type - male/female
Male
Connection no 1 type - male/female
Male
CConnection centre to insert distance
65,4 mm
DConnection 2, centre to end distance
33 mm
Manufacturer
Alfagomma
