Home
Attachments & Lift
Hydraulic Systems
Hydraulic Control Valves
ARAG - 8710502 - Electric Main Switch Valve
ARAG - 8710502 - Electric Main Switch Valve
ARAG - 8710502 - Electric Main Switch Valve
ARAG - 8710502 - Electric Main Switch Valve

In stock - ready to ship

Order now for delivery between 16 May and 20 May
Free shipping

Pay Securely with

ARAG - 8710502 - Electric Main Switch Valve

ARAG - 8710502 - Electric Main Switch Valve

€173.15

(Excl. VAT)

Price

(Excl. VAT)

€173.15

Arag
Arag manufactures lubrication and fluid management systems for agricultural machinery. The brand produces oil pumps, filters, and cooling systems for tractors and harvesters. Its solutions enhance equipment longevity and efficiency in farming operations. Shop more than 2,518 genuine Arag spare parts.

Product Details

Brand
Arag
Unit
Each
Voltage
12 V
Flow max.
150 l/min
max. Flow
150 l/min
Connection
863
Properties
Housing made from fibreglass-reinforced nylon Inner parts made from Delrin® and Inox steel AISI 303 Viton® seals Are equipped with hose nipples for the process. Further connections can be found under "easylink" P214373 (series 464) and P217817 (series 471)
Consists of
Composed of an electrical main switch valve (with gear motor) with adjustable pressure-relief valve
P max. (bar)
20 BAR
Hose Ø input
25 mm
Response time
0,6 s
Hose Ø bypass
30 mm
Application range
Gear motor: controls the opening/closing of the main control valve and consequently the discharging of the liquid via the system. (Open valve: the liquid is delivered to the operating circuit; closed valve: the liquid is delivered to the tank) Pressure relief valve: Releases the available liquid surplus when the programmed maximum pressure is reached. The valve can be adjusted manually Suitable for screwed fittings When using fittings in modular form, use an adapter (463/ T5 or 464/ T5)
Power consumption
0,5 A
Manufacturer
Arag
