Benefits
Minimum repair costs thanks to the unique automatic protection system As pumps from B.P. are tested, inspected and packaged with the utmost care, trouble-free start-up is 100% guaranteed
Properties
These pumps can generate both positive pressure and vacuum
Consists of
Without pressure relief valve (item 0200013) and vacuum valve (item 0155513) The pumps are delivered without lubrication oil (item BP5070) Without pulley
Technical info
Composition of item numbers: MEC= series, 9000= type, P= pulley drive, B= ballast system, A= automatic lubrication On pumps without automatic lubrication (no "A" in the item number), the pump is equipped with a forced lubrication system that is adjusted using dripper nozzles Automatic lubrication available on request On pumps without automatic lubrication, the quantity of lubrication oil is set in the factory and cannot be changed without a tool In the case of forced lubrication, as with automatic lubrication, the function must be checked at all times during operation Pumps with pulley drive rotate clockwise. Counterclockwise rotation with 'L' in the item number or available on request The direction of rotation is determined when the axle to be driven is aligned with the observer Oil to be used for lubricating the vanes: genuine oil from B. P. (item number BP5070)
Application range
These vacuum pumps with vanes are mainly used in agriculture for filling and emptying slurry tanks
Max. shaft rotation
1400 r/min
Direction of rotation
Counter-clockwise (CCW)
Max. relative pressure
1,5 BAR
Crash protection system
Yes
Lubrication system type
Forced
FMounting holes diameter
22 mm
Nominal volume flow rate
9030 l/min
B,LMounting holes distance
189 mm246 mm
Ballast air injection system
No
D,PDiameter of hose connection
80 mm
CMounting holes to end distance
141 mm
IShaft centre to bottom distance
164 mm
Safety valve connection diameter
2 Inch
Power requirement for max. vacuum
16 kW
Power requirement for max. pressure
25 kW
Depression valve connection diameter
1-1/2 Inch
AMounting holes to shaft end distance
205 mm
MShaft centre to left side end distance
195 mm
NShaft centre to right side end distance
195 mm
Manufacturer
Battioni Pagani
