Burkert - 6281-EV-B40,0BBMSGM88-5-024/50-221947 - 2/2-Way Solenoid Valve, Servo Controlled

SKU: burkert-6281-ev-b40-0bbmsgm88-5-024-50-221947

Browse all parts
Burkert - 6281-EV-B40,0BBMSGM88-5-024/50-221947 - 2/2-Way Solenoid Valve, Servo Controlled

€447.02€382.07 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€447.02

Brand
Burkert
CE Mark
Yes
AC Voltage
Yes
DC Voltage
No
Coil Size (mm)
32
Rated Power (W)
7
Mode Of Operation
B - in Ruhestellung geöffnet - Druckanschluss 1 (P/NO)
Material - Seal Seat
NBR (Nitrilkautschuk)
Line Connection 2 Type
Innengewinde
Voltage Frequency (Hz)
50
Nominal Pressure Min (bar)
0,2
Pilot Control Seal Material
NBR (Nitrilkautschuk)
Sealing To Outside Material
NBR (Nitrilkautschuk)
Seat Seal Material Category
Elastomere
Medium Temperature Max (°C)
80
Medium Temperature Min (°C)
-10
Ambient Temperature Max (°C)
55
Line Connection 2 Thread Type
G
Nominal Pressure (DIN EN 1333)
PN 16
Main Valve Nominal Size 1 (inch)
1 1/2
Voltage Max. / Rated Voltage (V)
24
Voltage Min. / Rated Voltage (V)
24
Main Valve Nominal Size 1 (P) (mm)
40
Nominal Pressure Max (Liquid) (bar)
16
Line Connection 2 Thread Designation
1 1/2
Main Valve Material, Media-contacting
Messing
EAN
4053913017937
Manufacturer
Burkert
