Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le
Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le
Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le
Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le
Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le
Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le

Casappa - KP4087S085E5 - Tandem Pump Kp40.87s0-85e5-Le

€1,071.68

(Excl. VAT)

Price

(Excl. VAT)

€1,071.68

Casappa
Casappa specializes in hydraulic systems and components for agricultural machinery, including pumps, motors, and valves. The brand is known for its high-performance solutions that enhance the efficiency of tractors and farming equipment. Its products are widely used in irrigation systems, harvesters, and other heavy-duty agricultural applications. Shop more than 566 genuine Casappa spare parts.

Product Details

Brand
Casappa
Unit
Each
Benefits
Wide range of applications Can be used in challenging environmental conditions
Properties
Consists of 3 parts Customer-specific design possible
Shaft type
Tapered
Flange code
E5
Displacement
86,56 cm³/rev
Sealing type
Standard
Port position
Side
AHousing length
170 mm
Flange type norm
European
Housing material
Steel
Application range
Mobile applications Industrial applications
Mounting diameter
63,5 mm
Max rotation speed
2800 r/min
Shaft cone size code
1:8
Number of mounting holes
4
Prefered rotation direction
Counter-clockwise (CCW)
Flange and back cover material
Steel
Max. continous working pressure
280 BAR
BConnection port to flange distance
120 mm
DSuction port bolts circle diameter
72 mm
EPressure port bolts circle diameter
51 mm
Manufacturer
Casappa
