Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el
Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el
Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el
Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el
Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el
Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el

In stock - ready to ship

Order now for delivery between 23 May and 27 May
Free shipping

Pay Securely with

Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el

Casappa - PLM106R81E1 - Motor plm10.6,3r0-81e1-lba/bb-n-el

€201.45

(Excl. VAT)

Price

(Excl. VAT)

€201.45

Product Description

European flange Tapered shaft 1:8 European front flange Spigot 25.4mm Drain connection 1/8" BSP, connect to free return, max. : 5 bar Limited axial and radial loads For chain and belt drives, it is necessary to use a support bearing
Casappa
Casappa specializes in hydraulic systems and components for agricultural machinery, including pumps, motors, and valves. The brand is known for its high-performance solutions that enhance the efficiency of tractors and farming equipment. Its products are widely used in irrigation systems, harvesters, and other heavy-duty agricultural applications. Shop more than 567 genuine Casappa spare parts.

Product Details

Brand
Casappa
B
40 mm
D
30 mm
E
30 mm
Note
Always connect leakage oil line
Pros
Versatile for heavy-duty conditions
Seal
Order no.: PLM 9-10AFD
Unit
Each
Material
Aluminium
P1 (bar)
230 BAR
Shaft type
Conical 1:8
Length body
83 mm
Rotation max.
3500 r/min
Stroke volume
6,67 cm³/rev
Suction flange
1 GQ-08
Pressure flange
1 GQ-08
Rotational speed min.
650 r/min
Manufacturer
Casappa
