DAB - DAB90270 - Submersible Pump Drainage 600M-A

SKU: dab-dab90270

DAB - DAB90270 - Submersible Pump Drainage 600M-A

€387.02

(excl. VAT)
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Price

(Excl. VAT)

€387.02

The DAB NOVA 600 M-A, part number 90270, is a genuine DAB 0.55 kW (0.75 HP) single-phase submersible drainage pump designed for clean water without solids or abrasive substances. This pump features an automatic float switch for reliable operation, indicated by the 'M-A' designation. It offers a maximum flow rate of 16 m³/h and a maximum head of 10.2 meters. With a maximum immersion depth of 7 meters and a 10-meter power cable, it is suitable for various domestic drainage applications. The pump is built with an IP68 motor protection rating and F insulation class, ensuring durability and safety in operation.
DAB
Dab specializes in agricultural machinery, offering a range of tractors and tractor attachments for soil preparation and cultivation. The brand is known for its durable and efficient equipment designed for small to medium-sized farms. Its products include plows, harrows, and seeders tailored for precision farming. Shop more than 56 genuine Dab spare parts.

Brand
DAB
Part Numbers
dab90270
Unit
Each
Height
234 mm
Weight
6,2 kg
Details
Handle insulated with rubber Thermal fuse fitted as standard
Benefits
Safe High level of operational reliability
Frequency
50 Hz
Properties
Double mechanical seal Motor shaft made of stainless steel AISI 316 Rear-mounted vortex impeller made from precision-cast stainless steel AISI 304 Permanently switched-on capacitor in the mains power version
Consists of
Pump housing, seal, filter and filter cover, motor housing, pump sleeve with handle and lid of the cable storage made of stainless steel AISI 304
Total width
154 mm
Cable length
10 m
Rated voltage
220-240 V
Nominal current
3 A
Application range
For rainwater, ground water, sandy water from construction sites and mildly contaminated waste water Not suitable for aggressive liquids Maximum grain size that can pass though the pump mesh: 10 mm
Max delivery height
10 m
Max. volume flow rate
13,5 m³/h
Motor power output (P2)
0,45 kW
Max. solids size for free passage
10 mm
Max. medium temperature (continuous)
35 °C
Min. medium temperature (continuous)
0 °C
Thread diameter of suction side connection
1-1/4 Inch
Manufacturer
DAB
