Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06
Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06
Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06
Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06
Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06
Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06

Danfoss - CB10HVM03005 - Danfoss Balancing Valve 1B1E100B00 NG06

€173.42

(Excl. VAT)

Price

(Excl. VAT)

€173.42

Product Description

Allows smooth, controlled movement Enables accurate positioning of pulling and pushing loads
Danfoss
Danfoss develops advanced hydraulic and electronic control systems for agricultural machinery, including tractors and harvesters. The brand is known for its energy-efficient solutions, such as pumps, valves, and power units. Its technologies optimize precision and productivity in modern farming operations. Shop more than 1,238 genuine Danfoss spare parts.

Product Details

Brand
Danfoss
Unit
Each
Cavity
MFN-G06-010
Details
Allows smooth, controlled movement Enables accurate positioning of pulling and pushing loads
Benefits
Protects consumer against cavitation Protects against pressure peaks caused by external forces
Size code
Cetop 03
Thickness
1,5 mm
Properties
Adjustable load-holding and counterbalance functions in A and B lines Modular construction, hex adjustment Suitable for: high pressure and medium volume flow Free flow from P to A/B Release of A or B to P (T) by means of control pressure from the opposite line
Consists of
Cartridge Housing Seal carrier
Pilot ratio
4.5:1.0
Total width
48,5 mm
Total height
45 mm
Total length
100 mm
Max. flow rate
35 l/min
Pressure range
20-70 BAR
Technical info
Opening pressure depends on pressure setting, load pressure and control pressure ratio Double-acting Cartridge construction Control valve should have ABT connection in neutral position Pressure setting 30% higher than the maximum load pressure
Adjustment type
External
Housing material
Aluminium
Sealing material
Nitrile rubber [NBR] Viton
Application range
Movement control Load holding Intermediate plate valve for NG6 valve blocks
Max working pressure
210 BAR
Manufacturer
Danfoss
