Danfoss - OMTS500151B3041 - Orbit Motor Short
Danfoss - OMTS500151B3041 - Orbit Motor Short
Danfoss - OMTS500151B3041 - Orbit Motor Short
Danfoss - OMTS500151B3041 - Orbit Motor Short
Danfoss - OMTS500151B3041 - Orbit Motor Short
Danfoss - OMTS500151B3041 - Orbit Motor Short
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Danfoss - OMTS500151B3041 - Orbit Motor Short

Danfoss - OMTS500151B3041 - Orbit Motor Short

€1,188.02

(Excl. VAT)

Price

(Excl. VAT)

€1,188.02

Danfoss
Danfoss develops advanced hydraulic and electronic control systems for agricultural machinery, including tractors and harvesters. The brand is known for its energy-efficient solutions, such as pumps, valves, and power units. Its technologies optimize precision and productivity in modern farming operations. Shop more than 1,238 genuine Danfoss spare parts.

Product Details

Brand
Danfoss
Unit
Each
Max. power
26,5 kW
Shaft type
Straight parallel
Displacement
500 cm³/rev
Flange shape
Short
L1Rotor length
61,5 mm
Max. flow rate
125 l/min
Shaft diameter
37,6 mm
Technical info
Orbital motor offers compact construction and simple mounting. High torque and shaft load, because of shorter distance from mounting flange to the point of load application.
LHousing length
191 mm
Application range
In combination with gearboxes, e.g., as a wheel drive
Max pressure peak
210 BAR
Max rotation speed
240 r/min
Min rotation speed
5 r/min
Main port thread type
G
Max continuous torque
1220 N·m
Shaft number of teeth
16
Drain port thread type
G
Number of mounting holes
4
Main port thread diameter
3/4 Inch
Drain port thread diameter
1/4 Inch
Max. continous working pressure
160 BAR
Max intermittend working pressure
180 BAR
Manufacturer
Danfoss
