Danfoss - SVP08CDB003 - Control Valve 2/2 Svp08Cdb 24 Vdc

OEM Supplier

SKU: danfoss-svp08cdb003

Danfoss - SVP08CDB003 - Control Valve 2/2 Svp08Cdb 24 Vdc

€103.31€88.30 (Excl. VAT)

RRP:€127.13
Save €23.82
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €11.99 incl. VAT

Pay Securely with

Price

€103.31

Brand
Part Number
SVP08CDB003
Package length (mm)
84
Package width (mm)
73
Package height (mm)
34
Type
Normally close (NC)
Unit
Each
Flow rate
16 l/min
Duty cylce
100 %
Properties
Voltage can be varied by replacing the coil
Consists of
Cartridge Housing Coil Without plug
Thread type
BSP
Max. leakage
6 cm³/min
Voltage (DC)
24 V
Pilot pressure
3 BAR
Technical info
Integrated line valve Seat valve, electrical on/off
Housing material
Aluminium
Sealing material
Nitrile rubber [NBR]
Application range
High pressure and medium volume flow Cut-off valve Way valve
Max working pressure
230 BAR
Port thread connection
3/8 Inch
Manufacturer

The Danfoss 2/2-way control valve, part number SVP08CDB003, operates normally closed with 24 VDC and BSP thread. It includes a cartridge, housing, solenoid coil, and no plug. Made by a company that also supplies parts to machine manufacturers, it functions as an electrically operated on/off seat valve with integrated pilot valve.
Danfoss
Danfoss A/S is a global leader in climate and energy-efficient solutions, founded in 1933 by Mads Clausen on his parents' farm in Nordborg, Denmark. The company began with the invention of the expansion valve for refrigeration systems and has since grown into a multinational corporation. Headquartered in Nordborg, Denmark, Danfoss remains a privately held company, known for its innovative approach to engineering and sustainable technologies. Danfoss offers a broad portfolio of products across various segments, including heating, cooling, power solutions, and drives. In the agricultural sector, its hydraulic and electronic control systems are vital components for modern machinery. The brand is recognized for its advanced hydrostatic transmissions, such as the H1 series, and its comprehensive range of hydraulic pumps, motors, valves, and steering components, which enhance precision and efficiency in tractors, harvesters, and other heavy equipment. Partao provides a wide selection of genuine Danfoss spare parts, including Seal Kits, Air Filters, Ball Bearings, Bearing Housings, and Bolts & Fasteners. Agricultural professionals worldwide choose Danfoss components for their robust construction, advanced control capabilities, and contribution to operational efficiency. The brand's commitment to developing intelligent and energy-saving solutions helps farmers and operators optimize their machinery's performance, reduce fuel consumption, and achieve greater productivity in demanding field conditions. Shop more than 1,904 genuine Danfoss spare parts.
