Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball
Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball
Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball
Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball
Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball

Di Natale Bertelli - TC5034 - Telescopic Cylinder TC 5034 Ball

€1,805.33

(Excl. VAT)

Price

(Excl. VAT)

€1,805.33

Product Description

The Di Natale-Bertelli TC5034 is a robust telescopic hydraulic cylinder featuring a ball mounting type. This genuine Di Natale-Bertelli component is engineered for reliable performance in demanding agricultural and industrial machinery, providing efficient lifting and extension capabilities. Key specifications include a bore of 50 mm, a stroke of 340 mm, and a closed length of 210 mm, making it suitable for various applications requiring precise hydraulic control.
Di Natale Bertelli

Product Details

Brand
Di Natale-Bertelli
Unit
Each
Stroke
2005 mm
Weight
131 kg
Properties
Unpainted Low installation dimensions Excellent running properties Long service life
DIN standard
1629
LMin. length
633 mm
Oil capacity
31 l
Number of stages
5
Sealing material
Polyurethane
Stage 1 diameter
107 mm
Stage 2 diameter
126 mm
Stage 3 diameter
145 mm
Stage 4 diameter
165 mm
Stage 5 diameter
187 mm
Application range
Trailer tipping cylinder Vehicle construction
Cylinder material
Steel S355J2+N
DOutside diameter
215 mm
Max. piston speed
0,5 m/s
Application category
Telescopic
CSide shaft diameter
50 mm
Max. working pressure
180 BAR
Vickers hardness (HV)
HV5/12=500/550
BOil connection length
50 mm
Max. capacity - stage 2
22,4 t
Max. capacity - stage 3
29,7 t
Max. capacity - stage 4
38,4 t
Max. capacity - stage 5
49,4 t
Max. capacity at 180 bar
49,4 t
Oil connection thread type
Metric
Oil connections thread pitch
1.50 mm
Mounting type - rod connection
Ball
Oil connection thread diameter
M22
Piston surface roughness range
0.05-0.15 µm
IMounting bush outside diameter
150 mm
Mounting type - cylinder connection
Trunnion
C1Oil connection to rod end distance
258 mm
FMounting hole to swivel tap distance
375 mm
HMounting hole diameter - rod connection
73 mm
Mounting hole diameter - cylinder connection
50 mm
Manufacturer
Di Natale-Bertelli
