Eaton - DILM701400VAC - Contactor 7A 3.5kW
Eaton - DILM701400VAC - Contactor 7A 3.5kW
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping on orders over €60

Pay Securely with

Eaton - DILM701400VAC - Contactor 7A 3.5kW

Eaton - DILM701400VAC - Contactor 7A 3.5kW

€38.87

(Excl. VAT)

Price

(Excl. VAT)

€38.87

Eaton
Eaton specializes in hydraulic systems, power transmission, and control technologies for agricultural machinery. The brand provides components like valves, pumps, and hoses used in tractors and harvesting equipment. Its solutions enhance efficiency and reliability in demanding farming and forestry operations. Shop more than 585 genuine Eaton spare parts.

Product Details

Brand
Eaton
Unit
Each
Depth
75 mm
Width
45 mm
Height
68 mm
Voltage type
AC
Technical info
The newly developed DILM contactors switch motors up to 170 A. Significantly improved performance features such as pickup and holding powers, optimised dimensions and advantages during installation transform the contactor relays to an absolute top product. Engineering: 4 sizes cover the performance range up to 170 A Only 3 widths up to 170 A Integrated auxiliary contacts Mounting: Twin box terminals with contactors from 7 A to 170 A Coil connection located at the front AC and DC contactor relays have the same dimensions. Operation: Integrated suppressor with DC operated contactors AC suppressor is simple to plug-in Low holding powers with DC contactor DC universal voltage coils from 17 A
Modular version
No
Manufacturer Product ID
276587
Operating voltage AC 50 Hz
400-400 V
Operating voltage AC 60 Hz
24.0-690.0 V
Rated operation power NEMA
2,2 kW
Rated operation power at AC-3, 400 V
3 kW
Rated operation power at AC-4, 400 V
2,2 kW
Rated control supply voltage Us at DC
0.0-0.0 V
Rated operation current Ie at AC-4, 400 V
5 A
Rated control supply voltage Us at AC 50HZ
400.0-400.0 V
Rated control supply voltage Us at AC 60HZ
440.0-440.0 V
Rated operating current (Ie) at AC-1, 400 V
22 A
Rated operating current (Ie) at AC-3, 400 V
7 A
Type of electrical connection of main circuit
Screw connection
Number of normally open contacts as main contact
3
Number of normally closed contacts as main contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
1
Manufacturer
Eaton
