Eaton - LSS11S - Limit Switch, Plastic

OEM Supplier

SKU: eaton-lss11s

Eaton - LSS11S - Limit Switch, Plastic

€31.55

(excl. VAT)

In stock - ready to ship

Ships within 48 hours
Free shipping on orders over €60

Pay Securely with

Price

(Excl. VAT)

€31.55

The Eaton LSS11S is a genuine Eaton industrial limit switch featuring a durable plastic body and a plunger actuator. Designed for robust applications, it provides reliable position sensing with 1 normally open (NO) and 1 normally closed (NC) snap-action contact configuration. This LSS series switch is IP67 rated, ensuring protection against dust and water ingress, making it suitable for demanding industrial environments. It offers a current rating of 10A and a voltage rating of 600V AC / 250V DC, with screw terminal connections. The compact dimensions are 30.5mm width, 60.5mm height, and 31.5mm depth, operating effectively in temperatures from -25°C to +70°C.
Eaton
Eaton specializes in hydraulic systems, power transmission, and control technologies for agricultural machinery. The brand provides components like valves, pumps, and hoses used in tractors and harvesting equipment. Its solutions enhance efficiency and reliability in demanding farming and forestry operations. Shop more than 122 genuine Eaton spare parts.

Brand
Eaton
Part Numbers
lss11s
Unit
Each
Cable entry
M20
Width sensor
31 mm
Forced opening
Yes
Technical info
Screw terminals Ending SW: complete black, else yellow hood Number has D in code : Contact close before break (delay) First number: amount if NO contacts Second number: amount of NC contacts LSE : Electronic circuit LSE-AI: Analog output 4-20mA LSE-AU: Analog output 0-10V
Diameter sensor
0 mm
Protection type
IP66
Height of sensor
61 mm
Insulation class
66 67
Length of sensor
33,5 mm
Material housing
Plastic
According to norm
LS,LSM: IEC/EN 60947 LSE: IEC/EN60947, EN61000-4
Output electronic
No
Type of interface
None
Switching function
Quick-break switch
Number of NC contacts
1
Number of NO contacts
1
With status indication
No
Manufacturer Product ID
106798
Type of control element
Plunger
Construction type housing
Cuboid
Terminal capacities (mm2)
1x (0,5 - 2,5) mm²
Switching function latching
No
Type of electric connection
Cable entry metrical
Suitable for safety functions
Yes
Switching capacity (AC-15 24V)
6 A
Switching capacity (DC-13 24V)
10 A
Alignment of the control element
Roller cam straight
Switching capacity (AC-15 115V)
6 A
Switching capacity (AC-15 400V)
4 A
Switching capacity (DC-13 110V)
1 A
Switching capacity (DC-13 220V)
0,5 A
Explosion safety category for gas
None
Explosion safety category for dust
None
Number of safety auxiliary contacts
1
Ambient temperature during operating
-25.0 °C
Switching capacity (AC-15 230V) (A)
6 A
Number of contacts as change-over contact
0
Rated operation current Ie at AC-15, 24 V
6 A
Rated operation current Ie at DC-13, 24 V
3 A
Rated operation current Ie at AC-15, 125 V
6 A
Rated operation current Ie at AC-15, 230 V
6 A
Rated operation current Ie at DC-13, 125 V
0,8 A
Rated operation current Ie at DC-13, 230 V
0,3 A
Type of interface for safety communication
None
Number of contacts as normally open contact
1
Number of contacts as normally closed contact
1
EAN
4015081065653
Manufacturer
Eaton
