Emmegi - OK2MV524301 - Emmegi Oil Cooler (24 V) 48-60°C MV-5

SKU: emmegi-ok2mv524301

Emmegi - OK2MV524301 - Emmegi Oil Cooler (24 V) 48-60°C MV-5

€1,427.59€1,220.16 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,427.59

Brand
Emmegi
Part Numbers
OK2MV524301
Unit
Each
BWidth
610 mm
Bypass
Yes
EDepth
240 mm
AHeight
515 mm
Amperage
13,1 A
Includes
Aluminium radiator Electric motor with impeller Temperature switch 48-60ºC Bypass Plug connection Without mounting base
Material
Plastic Aluminium
Technical info
Air oil-coolers are applied to improve heat exchange between oil and the environment. The coolers are supplied standard with a 48 - 60 °C thermostat.
Nominal voltage
24 V
Product details
Outstanding value for money With thermostat and bypass Highly suitable for mobile applications.
Insulation class
68
Long description
Oil coolers are used to improve heat exchange between oil and environment. The 2MV coolers are fitted with a thermostat as well as a bypass as standard.
Drive motor power
340 W
Max. working flow
140 l/min
Fan outside diameter
385 mm
Max. working pressure
20 BAR
Cooling medium flow type
Suction
LMounting holes distance
400 mm
PConnection thread diameter
1-1/4 Inch
Thermostat working temperature
48-60
Manufacturer
Emmegi

Oil coolers are used to improve heat exchange between oil and environment. The 2MV coolers are fitted with a thermostat as well as a bypass as standard.
Emmegi
Emmegi is a supplier of agricultural machinery components, including hydraulic cylinders and power transmission systems. The brand specializes in high-performance parts for tractors and harvesting equipment. Its products are known for precision engineering and long service life. Shop more than 329 genuine Emmegi spare parts.
