Festo - 8208382 - Manifold Plate

SKU: festo-8208382

Festo - 8208382 - Manifold Plate

€459.97€393.14 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 4 to 6 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€459.97

Brand
Festo
Size
2
Report
PROFINET
KC-mark
KC-EMV
Permission
RCM mark
Cable Output
straight
Nut Material
High-alloyed stainless steels
Material Note
RoHs compliant
Cover Material
PA reinforced
Fastening Type
mit Durchgangsbohrung für Schraube M5
Seals Material
NBR
Clamps Material
High-alloyed stainless steels
Sleeve Material
High-alloyed stainless steels
Shock Resistance
Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Diagnosis Via LED
Diagnose pro Modul
Max. Power Supply
2 x 4 A (externe Sicherung erforderlich)
Relative Humidity
5 - 95 %
Connection Position
On the side
Electrical Controls
AP-Schnittstelle
Protection Category
IP65
Dimensions W x L x H
26 mm x 104 mm x 92 mm
Max. Line Length (m)
50
Oscillation Strength
Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6
Max. Setup Height (m)
3.500
Over-voltage Category
II
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
für Cartridge 15 mm
Pneumatic Connection 5
für Cartridge 15 mm
Valve Island Structure
Valve sizes mixable
Degree Of Contamination
2
Nominal Altitude Of Use
<= 2000 m NHN
Voltage Supply, Function
Elektronik/Sensoren und Last kommend
Ambient Temperature (°C)
-5 to 50
Bearing Temperature (°C)
-20 to 70
Connection Plate Material
PA reinforced
Max. Number Of Valve Coils
128
Reverse Polarity Protection
yes
Inductive Protection Circuit
Integrated
Power Blackout Bridging (ms)
10
Power Consumption At 24 V DC
1,2
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Fastening Type Connection Plate
With throughway bores
Voltage Supply, Connection Type
socket / container / ….
Power Supply, Connection Pattern
995383
Communication Interface, Function
Systemkommunikation XF1 IN / XF2 OUT
Communication Interface, Protocol
PROFINET
Communication Interface, Shielding
yes
Communication Interface, Plug Pattern
995716
Information About Protection Category
ungenutzte Anschlüsse verschlossen
Voltage Supply, Connection Technology
M12x1 A coded to EN 61076-2-101
Voltage Supply, Number Of Poles/wires
5
Diagnostics Per Internal Communication
Überspannung Logikversorgung PS
Permissible Voltage Fluctuation Of Load
± 10 %
Communication Interface, Connection Type
2x socket
Nominal Operating Voltage DC Of Load (V)
24
Max. Tightening Torque Wall Assembly (Nm)
6
Protect Against Direct And Indirect Contact
SELV
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
Communication Interface, Number Of Pins/cores
4
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Communication Interface, Connection Technology
M12x1 D coded to EN 61076-2-101
Undervoltage Load/valves (Diagnostic Message) (V)
21,1
Permitted Voltage Oscillations Electronics/sensors
± 25 %
Nominal Operating Voltage DC Electronics / Sensor (V)
24
Intrinsic Power Input Operating Voltage Electronics/sensors
typisch 50 mA
Electrical Isolation Of Outputs Between Channel - Internal Communication
yes
Potential Separation Between The Supply Voltages Electronics/sensor Technology And Load/valves
yes
EAN
4052568790431
Manufacturer
Festo
