Festo - CDSU-1-8091509 - IO-Link Master USB

SKU: festo-cdsu-1-8091509

Browse all parts
Festo - CDSU-1-8091509 - IO-Link Master USB

€815.62€697.11 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€815.62

Brand
Festo
Report
IO-Link
Permission
RCM mark
Input Current
Max. 600 mA am USB-Anschluss
Input Voltage
24 V DC ± 6 V über externe Versorgung
Material Note
RoHs compliant
Output Voltage
24 V DC ± 6 V bei externer Versorgung (max. Eingangsspannung)
Housing Material
Aluminium-Knetlegierung, eloxiert
Overload Resistant
Not available
IO-Link, Port Class
B, mit Zubehör
Protection Category
IP20
Complies To Standard
EN 61131-9
LABS (PWIS) Conformity
VDMA24364-Zone III
IO-Link, Output Current
Max. Eingangsstrom bei externer Versorgung (<2,5 A)
IO-Link, Number Of Ports
1
Short Circuit Resistance
yes
Voltage Supply, Function
Zusatz-Spannungsversorgung
Ambient Temperature (°C)
0 to 55
Bearing Temperature (°C)
-10 to 75
IO-Link, Protocol Version
Master V 1.1
IO-Link, Communication Mode
COM1 (4,8 kBaud), COM2 (38,4 kBaud), COM3 (230,4 kBaud)
Reverse Polarity Protection
for operating voltage connections
USB Interface, Plug Pattern
995868
Electrical Connection IO-Link
3
IO-Link, Data Storage Provided
2 kByte / port
IO-Link, Process Data Width IN
parametrierbar 0 - 32 Byte
IO-Link, Process Data Width OUT
parametrierbar 0 - 32 Byte
Voltage Supply, Connection Type
socket / container / ….
IO-Link, Minimum Cycle Time (ms)
1,5
Power Supply, Connection Pattern
995993
USB Interface, Galvanic Isolation
yes
USB Interface, Connection Technology
USB 2.0 type B mini
Voltage Supply, Connection Technology
coaxial
Voltage Supply, Number Of Poles/wires
2
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection IO Link, Connection Type
socket / container / ….
Electrical Connection IO Link, Connection Technology
M12x1 A coded to EN 61076-2-101
Electrical Connection For IO-Link, Connection Pattern
991867
Electrical Connection IO Link, Number Of Pins / Wires
5
EAN
4052568451790
Manufacturer
Festo
