Festo - CMMO-ST-C5-1-DION-1512317 - Motor Controller

SKU: festo-cmmo-st-c5-1-dion-1512317

Browse all parts
Festo - CMMO-ST-C5-1-DION-1512317 - Motor Controller

€805.56€688.51 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€805.56

Brand
Festo
Display
Seven segment display
KC-mark
KC-EMV
Permission
RCM mark, c UL us - Listed (OL)
Step Setting
Via software
Fastening Type
on connection plate, With Slot rail, Permanently screwed
Network Filter
integrated
Safety Function
Safe switched off torque (STO)
Process Coupling
I/O coupling, for 32 mobile sets
Relative Humidity
0 - 90 %, Not condensing
Position Transducer
Encoder
Protection Category
IP40
Protection Function
I²t monitoring, Drag error monitoring, Software endpoint detection, Voltage blackout detection, Current monitoring, Temperature monitoring
Material Information
RoHs compliant
Performance Level (PL)
Safe Torque off (STO) / category 3, Performance Level e
Switching Logic Inputs
NPN (minus-switching)
Nominal Current Setting
Via software
Properties Logic Inputs
Galvanically connected with logic potential
Switching Logic Outputs
NPN (minus-switching)
Braking Resistance (Ohm)
15
Parameterising Interface
Ethernet
Ambient Temperature (°C)
0 to 50
Bearing Temperature (°C)
-25 to 75
Logic Input Specification
Depending on IEC 61131-2
Operating Mode Controller
PWN, MOSFET power end level, P position controller, Cascade controller with, PI speed controller, Proportional and integral controller for current
Rotor Position Transducer
Encoder
Work Area Logic Input (V)
24
Nominal Output Current (A)
5,7
Adjustable Current Lowering
Via software
Ethernet Supported Protocols
TCP/IP
Peak Current Load Supply (A)
8
Safety Integrity Level (SIL)
Safe switched off torque (STO) / SIL 3
Permitted Range Logic Voltage
± 15 %
Quantity Digital Logic Inputs
11
UL - Ambient Temperature (°C)
0 to 40
Nominal Current Load Supply (A)
6
Nominal Current Logic Supply (A)
0,3
Properties Digital Logic Outputs
Partially freely configurable, Not galvanically separated
Nominal Voltage Load Supply DC (V)
24
Encoder Input Interface, Properties
RS422
Nominal Voltage Logic Supply DC (V)
24
Impulse Power Braking Resistance (kVA)
0,1
Quantity Digital Logic Outputs 24 V DC
11
Max. Current Digital Logic Outputs (mA)
100
Max. Intermediate Circuit Voltage DC (V)
28
CE Certificate (See Declaration Of Conformity)
to EU EMC directive, to EU machinery directive
EAN
4052568238018
Manufacturer
Festo
