Festo - DSM-T-16-270-CC-A-B-1145094 - Swivel Drive

SKU: festo-dsm-t-16-270-cc-a-b-1145094

Browse all parts
Festo - DSM-T-16-270-CC-A-B-1145094 - Swivel Drive

€779.20€665.98 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€779.20

Brand
Festo
Size
16
Dampening
Stoßdämpfer beidseitig
Material Note
RoHs compliant
Fastening Type
with female thread
Seals Material
TPE-U(PU)
Housing Material
Aluminium wrought alloy
Operating Medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Swivel Angle (°)
0 to 246
Position Detection
For proximity switch
Repeatability (°)
0,1
Construction Set Up
Rotary vane
Dampening Angle (°)
12,0
Drive Shaft Material
nickel-plated
Fine Adjustment (°)
-3
Max. Axial Force (N)
30
Pneumatic Connection
M5
Installation Position
arbitrary
Max. Impact Force (N)
160
Max. Radial Force (N)
75
LABS (PWIS) Conformity
VDMA24364-B2-L
Principle Of Operation
double acting
Operating Pressure (MPa)
0,25 to 1
Ambient Temperature (°C)
-10 to 60
Permissible Stop Radius (mm)
17
Corrosion Resistance Class KBK
0 - No corrosion stressing
Permitted Mass Moment Of Inertia
0,02
Settings Range Swivel Angle (°)
0 to 246
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Theoretical Torque At 0.6 MPa (6 bar, 87 psi) (Nm)
5
Max. Swivel Frequency At 0.6 MPa (6 bar, 87 psi) (Hz)
1,0
EAN
4052568227463
Manufacturer
Festo
