Festo - EMMT-AS-80-S-HS-RMYB-8160645 - Servo Motor

SKU: festo-emmt-as-80-s-hs-rmyb-8160645

Browse all parts
Festo - EMMT-AS-80-S-HS-RMYB-8160645 - Servo Motor

€1,532.56€1,309.88 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,532.56

Brand
Festo
Max. Speed
8950
Permission
c UL us - Recognized (OL)
Maximum SIL
siehe Anwenderdokumentation
Detent Torque
<1,0% vom Spitzendrehmoment
Material Note
RoHs compliant
Safety Device
Sicherheitsbauteil
Motor Constant
0,74
Balance Quality
G 2,5
Measuring Flange
250 x 250 x 15 mm, Stahl
Peak Current (A)
5,4
Peak Torque (Nm)
2,8
Shock Resistance
Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Relative Humidity
0 - 90 %
Certification Body
UL E342973
Mass Inertia Brake
0,249
Nominal Torque (Nm)
1,3
Protection Category
IP40
Angular Acceleration
100000
Complies To Standard
IEC 60034
Number Of Pole Pairs
5
Oscillation Strength
Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6
PFHd, Part Component
15 x 10E-9, Encoder
Total Brake Friction
580
Installation Position
arbitrary
Max. Mechanical Speed
14.000
Max. Setup Height (m)
4.000
Brake Coil Inductivity
1000
LABS (PWIS) Conformity
VDMA24364-Zone III
Standstill Torque (Nm)
1,46
Temperature Monitoring
Digitale Motortemperaturübertragung per EnDat 2.2
Winding Switching Type
Star internal
Brake Closing Time (ms)
15
Degree Of Contamination
2
Maximum PL And Category
siehe Anwenderdokumentation
Heat Class To EN 60034-1
F
Interface Code Motor Out
80P
Max. Brake No-load Speed
10.000
Motor Type To EN 60034-7
IM V3
Nominal Rotational Speed
3000
Thermal Resistance (K/W)
0,95
Ambient Temperature (°C)
-40 to 40
Bearing Temperature (°C)
-40 to 70
Holding Torque Brake (Nm)
4,5
Nominal Current Motor (A)
1,76
Rotor Position Transducer
Safety Encoder absolut multi turn
Brake Separation Time (ms)
55
Standstill Torque Constant
0,89
Brake Coil Resistance (Ohm)
48
Electric Time Constant (ms)
4,8
Power Consumption Brake (W)
12
Thermal Time Constant (min)
42
DC Brake Response Delay (ms)
3
Switching Play Holding Brake
10 Mio. Leerbetätigungen (ohne Reibarbeit!)
Voltage Constant Phase-phase
53,6
Brake Current Consumption (A)
0,5
Nominal Performance Motor (W)
408
Corrosion Resistance Class KBK
0 - No corrosion stressing
Max. Winding Temperature (°C)
155
Safety Subfunctions Up To SIL3
Sichere Erfassung und Übertragung von Single-Turn-Positionsdaten, nur mit Zusatzsoftwarefunktion im Antriebsregler
Operating Voltage DC Brakes (V)
24
Safety Sub-functions Up To SIL2
Sichere Erfassung und Übertragung von Single-Turn-Positionsdaten
Total Output Moment Of Gyration
0,897
Winding Inductivity Phase-phase
39,8
Nominal Operating Voltage DC (V)
680
Continuous Standstill Current (A)
2
Permitted Axial Shaft Loading (N)
120
Number Of Emergency Stops Per Hour
1
Permitted Radial Shaft Loading (N)
620
Rotor Position Transducer Interface
EnDat 22
Winding Cross Inductivity Lq (Phase)
29,8
Winding Resistance Phase-phase (Ohm)
12,4
Information About Protection Category
IP67 für Motorgehäuse inklusive Anschlusstechnik
Max. Friction Per Braking Process (J)
8200
Safety Subfunction Up To PL E, Cat. 3
Sichere Erfassung und Übertragung von Single-Turn-Positionsdaten, nur mit Zusatzsoftwarefunktion im Antriebsregler
Duration Of Use Tm, Partial Components
20 years, rotor position sensor
Safety Sub-function Up To PL D, Cat. 3
Sichere Erfassung und Übertragung von Single-Turn-Positionsdaten
Electrical Connection 1, Connection Type
Hybrid plug
Bearing Lifetime Under Nominal Conditions
20.000
Measurement Class According To DIN 60034-1
S1
Rotor Position Transducer Resolution (Bit)
19
Electrical Connection 1, Connection Pattern
995913
Winding Longitudinal Inductivity Ld (Phase)
25
UKCA Marking (See Declaration Of Conformity)
nach UK Vorschriften für elektrische Betriebsmittel
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
M23x1
Electrical Connection 1, Number Of Pins / Wires
15
Rotor Position Sensor, DC Operating Voltage (V)
5
Rotor Position Sensor, Manufacturer Designation
EQI 1131
Rotor Position Transducer Measurement Principle
Inductive
Rotor Position Sensor, DC Operating Voltage Range (V)
3,6 to 14
Rotor Position Sensor, Position Values Per Revolution
524288
Rotor Position Sensor, Absolute Detectable Revolutions
4096
Concentricity, Coaxiality, Axial Runout To DIN SPEC 42955
N
Rotor Position Sensor, System Accuracy Of Angle Measurement
-120 to 120
EAN
4052568652111
Manufacturer
Festo
