Festo - ERMO-12-ST-E-3008525 - Rotary Actuator

SKU: festo-ermo-12-st-e-3008525

Browse all parts
Festo - ERMO-12-ST-E-3008525 - Rotary Actuator

€1,275.52€1,090.19 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,275.52

Brand
Festo
Size
12
Gear Ratio
09:01
Motor Type
Step motor
Permission
RCM mark
Material Note
RoHs compliant
Power-on Time
100%
Repeatability
±0.05 °
Fastening Type
with female thread
Flange Material
eloxiert
Mass Inertia JO
0,0079
Housing Material
eloxiert
Angle Of Rotation
Endless
Relative Humidity
Not condensing
Max. Speed At 90°
200
Construction Set Up
mit integriertem Getriebe
Nominal Torque (Nm)
0,15
Protection Category
IP40
Torsional Play (°)
0,2
Interface Code Basis
E8-35
Max. Axial Force (N)
180
Installation Position
arbitrary
Max. Radial Force (N)
200
LABS (PWIS) Conformity
VDMA24364-Zone III
Nominal Rotational Speed
100
Step Angle Tolerance (%)
±5
Ambient Temperature (°C)
0 to 50
Bearing Temperature (°C)
-20 to 60
Nominal Current Motor (A)
0,8
Rotor Position Transducer
Incremental encoder
Insulation Protection Class
B
Step Angle At Full Step (°)
1,8
Electrical Connection Technology
Plug
Nominal Operating Voltage DC (V)
24
Permitted Mass Moment Of Inertia
0,0003
Rotor Position Transducer Interface
RS422 TTL AB-Kanäle + Nullindex
Impact Energy At The End Positions (J)
0,00002
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
Bending Radius, Permanent Cable Placement (mm)
60
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Rotor Position Transducer Measurement Principle
Visual
EAN
4052568268053
Manufacturer
Festo
