Festo - KPE-8-178464 - Locking Unit

SKU: festo-kpe-8-178464

Browse all parts
Festo - KPE-8-178464 - Locking Unit

€527.93€451.22 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€527.93

Brand
Festo
Variants
One-sided piston rod
Material Note
RoHs compliant
Seals Material
TPE-U(PU)
Piston Material
POM
Safety Function
Halten und Anhalten einer Bewegung
Spring Material
spring steel
Housing Material
eloxiert
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Position Detection
without
Clamp Jaws Material
Brass
Construction Set Up
Tilting plates
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Release Pressure (MPa)
0,3
Operating Pressure (MPa)
0,3 to 1
Static Holding Force (N)
350
Ambient Temperature (°C)
-10 to 80
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Round Stock To Be Clamped (mm)
8
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Terminal Type With Effective Direction
Klemmung durch Feder, lösen durch Druckluft
EAN
4052568144289
Manufacturer
Festo
