Festo - LOE-1-D-MAXI-159623 - Lubricator

SKU: festo-loe-1-d-maxi-159623

Festo - LOE-1-D-MAXI-159623 - Lubricator

€290.83€248.57 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 4 to 6 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€290.83

Brand
Festo
Size
Maxi
Model Series
D
Material Note
RoHs compliant
Fastening Type
With Accessories
Clamps Material
PC
Clamp Protection
Metal protection basket
Operating Medium
Inerte Gase
Construction Set Up
Proportional standard oil mist lubricator
Installation Position
vertical ± 5°
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
G1
Pneumatic Connection 2
G1
Max. Oil Filling Volume
190,000
Medium Temperature (°C)
-10 to 60
Operating Pressure (MPa)
0 to 1.6
Ambient Temperature (°C)
-10 to 60
Bearing Temperature (°C)
-10 to 60
Air Purity Class At The Output
Inerte Gase
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Minimal Flow For Lubricator Function
10,000
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Standard Nominal Flow Rate (Standardised To DIN 1343)
9000
EAN
4052568126773
Manufacturer
Festo
