Festo - MS4N-EM1-1/8-541284 - Switch-On Valve

SKU: festo-ms4n-em1-1-8-541284

Browse all parts
Festo - MS4N-EM1-1/8-541284 - Switch-On Valve

€67.36€57.57 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€67.36

Brand
Festo
B-value
0.51
C-value
4,6
Control Type
Direct
Material Note
RoHs compliant
Actuation Type
Manually
Fastening Type
With Accessories
Flow Direction
Not reversible
Seals Material
TPE-U(PU)
Valve Function
3/2 bistable
Exhaust Function
Cannot be throttled
Housing Material
Aluminium die casting
Operating Medium
Inerte Gase
Food Compatibility
See expanded material information
Construction Set Up
Rotary disc
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
1/8 NPT
Pneumatic Connection 2
1/8 NPT
Pneumatic Connection 3
1/4 NPT
Medium Temperature (°C)
-10 to 60
Operating Pressure (MPa)
0 to 1,4
Ambient Temperature (°C)
-10 to 60
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Standard Nominal Flow Rate (Standardised To DIN 1343)
1200
EAN
4052568346751
Manufacturer
Festo
