Festo - NEBB-M12W5-P-2.5-LE3-8066679 - Connection Line

SKU: festo-nebb-m12w5-p-2-5-le3-8066679

Browse all parts
Festo - NEBB-M12W5-P-2.5-LE3-8066679 - Connection Line

€16.36€13.98 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€16.36

Brand
Festo
Wire Ends
Unshielded, Cut dull
Cable Set Up
3x0,25
Housing Colour
black
Seals Material
NBR
Line Properties
For static applications
Cable Length (m)
2,5
Housing Material
TPE-U(PU)
Line Designation
With Sign carrier
Cable Diameter (mm)
3,8
Cable Shield Colour
Grey
Protection Category
IP65, IP68, IP69K
Screw Lock Material
brass, nickel-plated
Complies To Standard
EN 61076-2-101, Wire colours and connection numbers acc. to EN 60947-5-2
Material Information
Copper and PTFE-free, RoHs compliant
Test Conditions Line
Test conditions on request
Cable Sleeve Material
PVC
Plug Contacts Material
Copper alloy gold plated
Degree Of Contamination
3
Ambient Temperature (°C)
-25 to 70
Insulation Sleeve Material
PVC
Surge Voltage Strength (kV)
2,5
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Operating Voltage Range AC (V)
0 to 250
Operating Voltage Range DC (V)
0 to 250
Electrical Connection 1, Design
round
Electrical Connection 1, Function
Field device screen
Electrical Connection 2, Function
Control screen
Electrical Connection 1, Cable Output
Angled
Information About Protection Category
In mounted condition
Current Carrying Capacity At 40°C (A)
4
Electrical Connection 1, Fastening Type
Schraubverriegelung mit SW13
Conductor - Nominal Cross-section (mm²)
0,25
Electrical Connection 1, Connection Type
socket / container / ….
Electrical Connection 2, Connection Type
cable
Electrical Connection 1, Occupied Pin / Wire
3
Electrical Connection 2, Occupied Pin / Wire
3
Bending Radius, Permanent Cable Placement (mm)
>= 12 mm
CE Certificate (See Declaration Of Conformity)
acc. to EU Low voltage Directive, acc. to EU-RoHS Directive
Electrical Connection 1, Connection Technology
M12x1 A coded to EN 61076-2-101
Electrical Connection 2, Connection Technology
Open end
Electrical Connection 1, Number Of Pins / Wires
5
Electrical Connection 2, Number Of Pins / Wires
3
EAN
4052568297213
Manufacturer
Festo
