Festo - NEBC-S1H15-E-10.0-N-LE15-2052919 - Control Cable

SKU: festo-nebc-s1h15-e-10-0-n-le15-2052919

Browse all parts
Festo - NEBC-S1H15-E-10.0-N-LE15-2052919 - Control Cable

€225.99€193.15 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€225.99

Brand
Festo
Wire Ends
Wire end sleeve
Cable Set Up
18x0,14
Cable Length (m)
10,00
Line Designation
Without sign holder
Cable Diameter (mm)
6,6
Cable Shield Colour
Grey
Protection Category
IP50
Complies To Standard
DIN 47100
Material Information
RoHs compliant
Cable Sleeve Material
TPE-U(PUR)
LABS (PWIS) Conformity
Cable track capable
Degree Of Contamination
3
Ambient Temperature (°C)
-30 to +80
Operating Voltage Range DC (V)
0 to 30
Electrical Connection 1, Function
Field device screen
Electrical Connection 2, Function
Control screen
Electrical Connection 1, Cable Output
straight
Information About Protection Category
In mounted condition
Electrical Connection 1, Fastening Type
2x Schraube 4-40 UNC-2A
Conductor - Nominal Cross-section (mm²)
0,14
Electrical Connection 1, Connection Type
Plug
Electrical Connection 2, Connection Type
cable
Electrical Connection 1, Connection Pattern
Angular
Electrical Connection 2, Connection Pattern
Open end
Electrical Connection 1, Occupied Pin / Wire
15
Electrical Connection 2, Occupied Pin / Wire
15
CE Certificate (See Declaration Of Conformity)
to EU low voltage directive
Electrical Connection 1, Connection Technology
Sub-D
Electrical Connection 1, Number Of Pins / Wires
15
Electrical Connection 2, Number Of Pins / Wires
15
EAN
4052568250720
Manufacturer
Festo
