Festo - PDAD-09-G3/8-552170 - Adsorption Dryer

SKU: festo-pdad-09-g3-8-552170

Browse all parts
Festo - PDAD-09-G3/8-552170 - Adsorption Dryer

€3,930.98€3,359.81 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€3,930.98

Brand
Festo
KC-mark
KC-EMV
Material Note
RoHs compliant
Fastening Type
With Accessories
Housing Material
Aluminium wrought alloy
Operating Medium
Druckluft nach ISO 8573-1:2010 [6:-:4]
Protection Class
II
Construction Set Up
Cold regenerated adsorption dryer
Protection Category
IP65
Installation Position
Horizontal
Over-voltage Category
II
Input Pressure 1 (bar)
4 to 16
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
G3/8
Pneumatic Connection 2
G3/8
Degree Of Contamination
2
Medium Temperature (°C)
2 to 50
Pressure Dew Point (°C)
-40
Ambient Temperature (°C)
5 to 50
Bearing Temperature (°C)
-20 to 60
Power Consumption At 230 V AC
16
Air Purity Class At The Output
Druckluft nach ISO 8573-1:2010 [2:2:2] bei -40°C
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Power Consumption At 24 V DC (W)
9,6
Electrical Connection 1, Function
Spannungsversorgung AC
Electrical Connection 2, Function
Spannungsversorgung DC
Note On Operating And Control Medium
kein Wasser in flüssiger Form
Electrical Connection 1, Connection Type
socket / container / ….
Electrical Connection 2, Connection Type
socket / container / ….
Pressure Dew Point For Reduced Flow (°C)
-70
Electrical Connection 1, Occupied Pin / Wire
2
Electrical Connection 2, Occupied Pin / Wire
2
UKCA Marking (See Declaration Of Conformity)
nach UK Vorschriften für elektrische Betriebsmittel
CE Certificate (See Declaration Of Conformity)
to EU low voltage directive
Electrical Connection 1, Connection Technology
Anschlussbild Form C nach Industriestandard 9,4 mm
Electrical Connection 2, Connection Technology
Anschlussbild Form C nach Industriestandard 9,4 mm
Electrical Connection 1, Number Of Pins / Wires
3
Electrical Connection 2, Number Of Pins / Wires
4
EAN
4052568193928
Manufacturer
Festo
