Material Note
phosphorsäureesterfrei
Housing Material
TPE-U(PUR)
Complies To Standard
EN 61076-2-101
LABS (PWIS) Conformity
VDMA24364-B2-L
Ambient Temperature (°C)
-25 to 85
Corrosion Resistance Class KBK
1 - low corrosion stress
Operating Voltage Range AC (V)
0 to 30
Operating Voltage Range DC (V)
0 to 30
Electrical Connection 1, Design
round
Electrical Connection 2, Design
round
Electrical Connection 1, Display
without
Electrical Connection 2, Display
without
Electrical Connection 1, Function
Field device screen
Electrical Connection 2, Function
Control screen
Electrical Connection 1, Cable Output
straight
Electrical Connection 2, Cable Output
straight
Electrical Connection 1, Fastening Type
drehbar
Electrical Connection 2, Fastening Type
drehbar
Electrical Connection 1, Connection Type
socket / container / ….
Electrical Connection 2, Connection Type
Plug
Electrical Connection 1, Connection Pattern
991861
Electrical Connection 2, Connection Pattern
997355
Electrical Connection 1, Occupied Pin / Wire
4
Electrical Connection 2, Occupied Pin / Wire
4
Electrical Connection 2, Terminal Allocation
Pin 5 = WH
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
Bending Radius, Permanent Cable Placement (mm)
14
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
M12x1 A-codiert nach EN 61076-2-101
Electrical Connection 2, Connection Technology
M12x1 A-codiert nach EN 61076-2-101
Electrical Connection 1, Number Of Pins / Wires
5
Electrical Connection 2, Number Of Pins / Wires
5
Suitability For The Production Of Li-ion Batteries
Geeignet für Batterieproduktion mit reduzierten Cu/Zn/Ni Werten (F1a)
Electrical Connection 1, Compatible Type Of Mounting
Kompatibel mit Schraubverriegelung drehbar/nicht drehbar
Electrical Connection 2, Compatible Type Of Mounting
Kompatibel mit Schraubverriegelung drehbar/nicht drehbar
Cleanroom Suitability, Measured According To ISO 14644-14
Klasse 4 nach ISO 14644-1
