Festo - VABF-S2-2-P1A3-G12-555786 - Vertical Supply Plate

SKU: festo-vabf-s2-2-p1a3-g12-555786

Browse all parts
Festo - VABF-S2-2-P1A3-G12-555786 - Vertical Supply Plate

€103.65€88.59 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€103.65

Brand
Festo
Material Note
RoHs compliant
Build Width (mm)
54,0
Housing Material
Aluminium die casting
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Based On Standard
ISO 5599-2
Protection Category
NEMA 4
Installation Position
arbitrary
Input Pressure 1 (bar)
0.5 to 10
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
G1/2
Operating Pressure (MPa)
-0,09 to 1
Pneumatic Height Linking
Alternative pressure supply for 1
Ambient Temperature (°C)
-5 to 50
Fastening Type Height Linking
auf Einzelanschlussplatte
Corrosion Resistance Class KBK
0 - No corrosion stressing
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
UKCA Marking (See Declaration Of Conformity)
nach UK Vorschriften für elektrische Betriebsmittel
CE Certificate (See Declaration Of Conformity)
to EU low voltage directive
Standard Nominal Flow Rate (Standardised To DIN 1343)
2800
EAN
4052568096359
Manufacturer
Festo
