Festo - VAD-3/8-19294 - Vacuum Suction Nozzle

SKU: festo-vad-3-8-19294

Browse all parts
Festo - VAD-3/8-19294 - Vacuum Suction Nozzle

€147.71€126.25 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€147.71

Brand
Festo
Max. Vacuum
80
Fastening Type
With throughway bores
Housing Material
Aluminium die casting
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Vacuum Connection
G3/8
Construction Set Up
T-shape
Installation Position
arbitrary
Ejector Characteristic
High vacuum
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
G3/8
Pneumatic Connection 3
G3/8
Medium Temperature (°C)
-20 to 80
Operating Pressure (MPa)
0,15 to 1
Ambient Temperature (°C)
-20 to 80
Nominal Width Laval Nozzle (mm)
1,5
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
EAN
4052568009465
Manufacturer
Festo
