Festo - VLX-2-3/8-MS-NPT-34923 - Pneumatic Valve

SKU: festo-vlx-2-3-8-ms-npt-34923

Browse all parts
Festo - VLX-2-3/8-MS-NPT-34923 - Pneumatic Valve

€309.11€264.20 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€309.11

Brand
Festo
Medium
Filtered compressed air, filter porosity 200 µm
Reset Mode
Pneumatic spring
Control Type
pilot operated
Actuation Type
pneumatic
Control Medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Fastening Type
pipe installation
Flow Direction
Not reversible
Valve Function
2/2 closed monostable
Screws Material
High-alloyed stainless steels
Exhaust Function
Cannot be throttled
Housing Material
Brass
Sealing Principle
Soft
Fitting Connection
NPT3/8
Nominal Width (mm)
13
Construction Set Up
diaphragm valve
Installation Position
arbitrary
Material Number Screw
14.301
Medium Pressure (bar)
1 to 10
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Medium Temperature (°C)
-10 to 80
Ambient Temperature (°C)
-10 to 60
Support Air Control Connection 12
M5
Standard Nominal Flow Rate (Standardised To DIN 1343)
3800
EAN
4052568305895
Manufacturer
Festo
