Festo - VPEV-1/8-150261 - Vacuum Switch

SKU: festo-vpev-1-8-150261

Browse all parts
Festo - VPEV-1/8-150261 - Vacuum Switch

€210.99€180.33 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€210.99

Brand
Festo
Permission
CCC
Material Note
RoHs compliant
Fastening Type
With throughway bores
Housing Material
Aluminium wrought alloy
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Measured Parameter
Relative pressure
Measurement Process
Pneumatic electric pressure converter
Protection Category
IP65
Complies To Standard
EN 60947-5-1
Minimum Load Current
100 mA bei 5V
Pneumatic Connection
G1/8
Electrical Connection
viereckige Bauform
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Switch Contact Material
silver
Use Category Ohmic Load
DC-12
Max. Output Current (mA)
5000
Medium Temperature (°C)
-20 to 80
Operating Pressure (MPa)
-0,1 to 0,16
Ambient Temperature (°C)
-20 to 80
Switching Element Function
changeover contact
Switching Status Indicator
LED yellow
Use Category Inductive Load
DC-13
Max. Switching Frequency (Hz)
3
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Max. Switch Off Voltage AC (V)
250
Max. Switch Off Voltage DC (V)
125
Pressure Measurement Range (MPa)
-0,1 to 0,16
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Settings Range Threshold Value (bar)
-0,95 to -0,2
UKCA Marking (See Declaration Of Conformity)
nach UK Vorschriften für elektrische Betriebsmittel
CE Certificate (See Declaration Of Conformity)
to EU low voltage directive
Settings Range Threshold Value After Retrofit (bar)
0.16 to 1.6
EAN
4052568116460
Manufacturer
Festo
