Festo - VSVA-B-P53F-ZD-D2-1T1L-8000465 - Solenoid Valve

SKU: festo-vsva-b-p53f-zd-d2-1t1l-8000465

Browse all parts
Festo - VSVA-B-P53F-ZD-D2-1T1L-8000465 - Solenoid Valve

€433.67€370.66 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€433.67

Brand
Festo
KC-mark
KC-EMV
Permission
c CSA us (OL), c UL us - Recognized (OL), C-Tick
Control Type
pilot operated
Actuation Type
Electrical
Fastening Type
on connection plate
Flow Direction
arbitrary
Seals Material
FKM, HNBR, NBR
Valve Function
5/3 vented 1 after 2, 4 after 5 closed
Screws Material
Zinc-plated steel
Build Width (mm)
52
Exhaust Function
drosselbar, über Drosselplatte, über Einzelanschlussplatte
Housing Material
PA, Aluminium die casting
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Power-on Time (%)
100
Sealing Principle
Soft
Control Air Supply
external
Flow Valve (l/min)
3.000
Construction Set Up
Piston pusher
Protection Category
IP65, NEMA 4
Complies To Standard
ISO 5599-2
Material Information
RoHs compliant
Pilot Air Port 12/14
Connection plate Size 2 to ISO 5599-2
Pitch Dimension (mm)
59
Hand Assist Actuation
Ratcheting, tentative
Installation Position
arbitrary
Shifting Time On (ms)
23
LABS (PWIS) Conformity
Plug-in, to ISO 5599-2
Pneumatic Connection 1
Connection plate Size 2 to ISO 5599-2
Pneumatic Connection 2
Connection plate Size 2 to ISO 5599-2
Pneumatic Connection 3
Connection plate Size 2 to ISO 5599-2
Pneumatic Connection 5
Connection plate Size 2 to ISO 5599-2
Shifting Time Off (ms)
60
Degree Of Contamination
3
Medium Temperature (°C)
-5 to 50
Operating Pressure (bar)
-0.9 to 10
Signal Condition Display
LED
Ambient Temperature (°C)
-5 to 50
Coil Characteristic Value
24 V DC: 4,6 W
Surge Voltage Strength (kV)
2,5
Corrosion Resistance Class KBK
0 - No corrosion stressing
Permitted Voltage Oscillations
± 10 %
Exhaust Control Connection 82/84
Selectively:, Recorded, Not recorded to standard
Support Air Control Connection 12/14
Connection plate Size 2 to ISO 5599-2
Nominal Current For Current Reduction
35 mA after 30 ms
Flow Valve Pneumatically Linked (l/min)
2.300
Nominal Tightening Current Per Solenoid
165 mA to 30 ms
Flow Valve Single Connection Plate (l/min)
2.600
CE Certificate (See Declaration Of Conformity)
to EU EMC directive
Information About Operating And Control Medium
Oiled operation possible (required in further operations)
0 - 90 %
Standard Nominal Flow Rate (Standardised To DIN 1343) (l/min)
2.300
EAN
4052568256159
Manufacturer
Festo
