Festo - VUVB-ST12-B52-ZD-QX-1T1-570910 - Solenoid Valve

SKU: festo-vuvb-st12-b52-zd-qx-1t1-570910

Browse all parts
Festo - VUVB-ST12-B52-ZD-QX-1T1-570910 - Solenoid Valve

€173.84€148.58 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€173.84

Brand
Festo
Control Type
pilot operated
Material Note
RoHs compliant
Power-on Time
100%
Actuation Type
Electrical
Fastening Type
on connection plate
Flow Direction
Not reversible
Seals Material
TPE-U(PU)
Valve Function
5/2 bistable
Valve Size (mm)
24
Exhaust Function
Cannot be throttled
Housing Material
PA reinforced
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Shock Resistance
Shock test with degree of severity 1 to FN 942017-5 and EN 60068-2-27
Sealing Principle
Soft
Control Air Supply
external
Nominal Width (mm)
4
Shifting Time (ms)
10
Construction Set Up
Poppet valve with self-retention
Protection Category
IP65
Oscillation Strength
Transport use test with severity level 1 to FN 942017-4 and EN 60068-2-6
Electrical Connection
Via connection plate
Hand Assist Actuation
tentative
Installation Position
arbitrary
Control Pressure (MPa)
0,28 to 0,8
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Piston Pusher Material
Aluminium wrought alloy
Pneumatic Connection 1
Connection plate
Pneumatic Connection 3
Connection plate
Pneumatic Connection 5
Connection plate
Medium Temperature (°C)
-5 to 60
Operating Pressure (MPa)
0,28 to 0,8
Ambient Temperature (°C)
-5 to 60
Coil Characteristic Value
24 V DC: 1,0 W
Sound Pressure Level (dB(A))
85
Corrosion Resistance Class KBK
0 - No corrosion stressing
Permitted Voltage Oscillations
± 10 %
Support Air Control Connection 14
Connection plate
Information About Operating Pressure
0 - 8 bar for external control air
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Max. Positive Test Impulse At 0 Signal
800
Max. Negative Test Impulse For 1 Signal
300
Standard Nominal Flow Rate (Standardised To DIN 1343)
260 to 450
EAN
4052568217495
Manufacturer
Festo
