FluidPress - FPO50DX38L20 - Double Equalising Valve
FluidPress - FPO50DX38L20 - Double Equalising Valve
FluidPress - FPO50DX38L20 - Double Equalising Valve
FluidPress - FPO50DX38L20 - Double Equalising Valve
FluidPress - FPO50DX38L20 - Double Equalising Valve
FluidPress - FPO50DX38L20 - Double Equalising Valve
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

FluidPress - FPO50DX38L20 - Double Equalising Valve

FluidPress - FPO50DX38L20 - Double Equalising Valve

€82.53

(Excl. VAT)

Price

(Excl. VAT)

€82.53

Product Description

Equalising valves or brake valves provide controlled movement, stopping and holding of loads. They prevent the lag of movements (negative load) and protect the installation against external forces (anti-shock). Overcentre valves provide controlled initiation and stopping of a movement, while holding the load at rest. When mounted directly on the cylinder or motor, they also function as hose breakage protection. Show more
Fluidpress

Product Details

Brand
FluidPress
Pros
Allows smooth, controlled movements and accurate positioning of pulling and pushing loads Hose breakage protection if fitted as close to the user as possible Negative final check
Type
Double
Unit
Each
Weight
0,84 kg
Includes
Cartridge Steel housing
Material
Aluminium
Extra info
DX : aluminium housing
Body length
150 mm
Pilot ratio
1:4.25
CTotal width
30 mm
Total length
246 mm
BTotal height
50 mm
Intended medium
Hydraulic oil
Sealing material
Buna-N
Nominal flow rate
50 NI/min
Max working pressure
210 BAR
Number of connections
4
Connections thread type
BSPP
Max working temperature
90 °C
Min working temperature
-20 °C
Mounting holes distance
33 mm
Adjustable pressure range
60-210 BAR
Standard pressure setting
170 BAR
Connections thread diameter
3/8 Inch
EConnections distance - long
111 mm
GConnections distance - short
48 mm
Manufacturer
FluidPress
