Hallite - U9511012 - Hallite U-Cup PU 95x110x12 e=13
Hallite - U9511012 - Hallite U-Cup PU 95x110x12 e=13
Hallite - U9511012 - Hallite U-Cup PU 95x110x12 e=13
Hallite - U9511012 - Hallite U-Cup PU 95x110x12 e=13

In stock - ready to ship

Order now for delivery between 23 May and 27 May
Free shipping on orders over €60

Pay Securely with

Hallite - U9511012 - Hallite U-Cup PU 95x110x12 e=13

Hallite - U9511012 - Hallite U-Cup PU 95x110x12 e=13

€7.56

(Excl. VAT)

Price

(Excl. VAT)

€7.56

Product Description

Seal for double-acting and single-acting cylinders Temperature range: -30°C to 100°C Material : polyurethane Symmetrical profile Max. 400 bar Series U type PU seals are replaced by Series SA-UN seals Types 605 and 663 have an asymmetrical profile* and are therefore only suitable for sealing piston rods. So never mount on a piston! Type 601 has a symmetrical profile* and is therefore suitable for both piston rod sealing and piston sealing. *Asymmetrical profile: the inner lip is shorter than the outer. *Symmetrical profile: both the inner and outer sealing lips are the same height. For an application specifically as a piston seal, please refer to type ZA-UN under piston seals.
Hallite

Product Details

Brand
Hallite
Pros
Highly flexible and easy assembly in closed room Very good oil resistance High tensile strength High wear resistance Suitable for both rod sealing and piston sealing
Type
Rod seal
Unit
Each
HWidth
12 mm
Material
Polyurethane
Type code
605
Properties
Highly flexible and therefore easy to install in enclosed chambers Highly oil-resistant High tensile strength High level of wear-resistance Suitable for use as a piston rod seal or piston gasket seal
Product details
Seal for double-acting and single-acting cylinders Temperature range: -30°C to 100°C Material : polyurethane Symmetrical profile Max. 400 bar Series U type PU seals are replaced by Series SA-UN seals Types 605 and 663 have an asymmetrical profile* and are therefore only suitable for sealing piston rods. So never mount on a piston! Type 601 has a symmetrical profile* and is therefore suitable for both piston rod sealing and piston sealing. *Asymmetrical profile: the inner lip is shorter than the outer. *Symmetrical profile: both the inner and outer sealing lips are the same height. For an application specifically as a piston seal, please refer to type ZA-UN under piston seals.
Long description
The cuffs made of polyurethane have a symmetrical profile, i.e. the sealing lips are the same length. This design allows these cuffs to be used for both rod and single-acting piston seals.
dInside diameter
95 mm
DOutside diameter
110 mm
EGroove thickness
13 mm
Max. sliding speed
1 m/s
Max. working pressure
400 BAR
Max. working temperature
110 °C
Min. working temperature
-45 °C
Manufacturer
Hallite
