HARTING - 09330102601 - PIN CONNECTOR E 10P SCREW TERMINAL
HARTING - 09330102601 - PIN CONNECTOR E 10P SCREW TERMINAL

In stock - ready to ship

Order now for delivery between 19 May and 22 May
Free shipping on orders over €60

Pay Securely with

HARTING - 09330102601 - PIN CONNECTOR E 10P SCREW TERMINAL

HARTING - 09330102601 - PIN CONNECTOR E 10P SCREW TERMINAL

€18.97

(Excl. VAT)

Price

(Excl. VAT)

€18.97

Product Description

The HARTING 09330102601 is a genuine Han E series 10-pole pin (male) connector insert designed for robust industrial applications. It features reliable screw termination technology, accommodating wire cross-sections from 0.75 mm² to 2.5 mm² (AWG 18-14). This connector is rated for a nominal current of 16A and a nominal voltage of 500V, ensuring secure and efficient power and signal transmission in demanding environments. Its compact design and durable construction make it suitable for use in various machinery and control systems.
Harting
Harting provides industrial-grade electrical and electronic connectors for agricultural machinery and automation systems. The brand's solutions ensure reliable power and data transmission in harsh farming environments. Its products are widely used in tractors, harvesters, and precision farming equipment. Shop more than 64 genuine Harting spare parts.

Product Details

Brand
harting
Series
Han E
Connector Type
insert
Gender
pin
Number Of Poles
10
Termination Method
screw
Rated Current (A)
16
Rated Voltage (V)
500
Rated Impulse Voltage Kv
6
Pollution (°)
3
Insulation Resistance Gohm
10
Contact Resistance Mohm
3
Material Contact
copper alloy
Material Insulator
polycarbonate (PC)
Flammability Rating
UL 94 V-0
Operating Temperature Min (°C)
-40
Operating Temperature Max (°C)
125
Wire Gauge Min (mm²)
0.75
Wire Gauge Max (mm²)
2.5
Wire Gauge Awg (min)
18
Wire Gauge Awg Max
14
Stripping Length (mm)
8
Torque (Nm)
0.5
Length (mm)
84
Width (mm)
34
Height (mm)
33
Manufacturer
harting
