HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V
HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V
HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V
HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V
HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V
HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V

In stock - ready to ship

Order now for delivery between 25 May and 28 May
Free shipping

Pay Securely with

HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V

HELLA - 1BL 012 488-121 - DE/LED-Insert, headlight, 90mm Performance L4060, 12/24V

€231.63

(Excl. VAT)

Price

(Excl. VAT)

€231.63

Product Description

HELLA 90mm modular headlights stand for the highest quality, reliability and cost efficiency. Whether bus, tractor, truck, motorhome or motorbike: The robust HELLA 90mm front headlights are used in many vehicle types. Thanks to their modular design, they offer maximum flexibility, which allows a wide range of applications as well as an individual front design. Within the 90mm modular headlamp range, a choice can be made between halogen and LED technology depending on requirements, which also facilitates the switch from halogen to LED. All modules score with a robust design and can therefore also be used in demanding working environments. The difference between the individual series of the 90mm range lies in the details. The L4060 LED modules, for example, shine with outstanding light output and additional lighting functions. The light colour of the LED modules, which is similar to daylight, significantly improves visibility and the ability to concentrate when driving at night, thus increasing safety. The L4565 Bi-LED modules as well as the BI-Halogen modules combine low beam and high beam in a single headlamp module and are therefore ideally suited for construction situations with limited space. The R80 modules have an innovative reflector design that ensures particularly homogeneous lighting.
Hella
Hella is a supplier of lighting and electronic systems for agricultural and off-road vehicles. The brand provides LED work lights, signal lamps, and electrical components for tractors and machinery. Its products are designed for durability and visibility in harsh farming environments. Shop more than 6,960 genuine Hella spare parts.

Product Details

Brand
HELLA
Equivalent OEM Part Numbers

Claas

18128450

Grimme

B94.08248

Heuliez

5802226449HZ5802226449

Holmer

1019057418

Iveco

5802226449E5802226449

Kässbohrer

7.512.318.000.0

Landini

6643064A1

Liebherr

12204972

Lindner

3010403

Mercedes Benz

9568200539A9568200539

Noge

PG00556003

Renault trucks

7422826409

Tatra

TW06426

Vinfast

BEX40000179BEX40000179-INSERT,HEADLIGHTBEX40000179-LOW_BEAM_DRL
Plug
DEUTSCH plug
SVHC
7439-92-1; Lead
Depth
143 mm
Shape
Round
Height
126 mm
Length
125 mm
Voltage
12 V / 24 V
Diameter
90 mm
Quantity
1
Lamp Type
LED
Lens Colour
Crystal clear
ECE Standard
R7 / R87 / R112
Light Design
DE / LED
Assembly Note
Assembly by qualified personnel required
Mounting Type
Fitting / Screw Connection
Fastening Type
3-point attachment
Housing Colour
Black
Light Function
With position light (LED) / with low beam (LED) / with daytime running light (LED)
Fitting Position
Both sides
Illuminated Area
62 mm
Traffic Orientation
For right-hand traffic
Supplementary Info 1
Electromagnetic Compatibility (EMC)
Supplementary Info 2
With accessories
Light Functions Count
3
Diffusing Lens Material
Thermoplast
Manufacturer
HELLA
