HELLA - 3AL 922 000-961 - Signal Horn, S90, 12V, 113dB(A), High Tone

OEM Supplier

SKU: hella-3al-922-000-961

HELLA - 3AL 922 000-961 - Signal Horn, S90, 12V, 113dB(A), High Tone

€10.86

(excl. VAT)

In stock - ready to ship

Ships within 96 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€10.86

Application: Horns are a mandatory part of every motor vehicle's safety equipment. A particularly well perceptible signal is necessary to be able to effectively warn other road users in dangerous situations. Our signal horns offer you a high level of functional safety. Structure and function: The horns are powered by the battery current, which is normally controlled by a control current from the steering wheel. This is routed to a relay that sends the entire control current so that no voltage dips occur. The control current activates the electromagnet in the horn and generates a magnetic field that attracts a metal core (armature) to which the steel diaphragm of the horn is attached. When energised, the power supply is interrupted, the magnetic field collapses, the armature and diaphragm return to the rest position and the power supply is restored. The process starts all over again. This creates a vibration that can be heard as a low or high tone.
Hella
Hella GmbH & Co. KGaA, commonly known as Hella, was founded in 1899 by Sally Windmüller in Lippstadt, Germany. Initially, the company produced lamps and horns for carriages, bicycles, and automobiles. Over its long history, Hella has evolved into a global, family-owned company, specializing in lighting and electronics for the automotive industry, with its headquarters still located in Lippstadt. Hella is renowned for its innovative lighting technologies, including LED, halogen, and xenon systems, as well as advanced electronic components. The brand's product range extends to sensors, actuators, and control units for various vehicle applications. In the agricultural sector, Hella provides robust and efficient lighting solutions, such as the Shapeline and Module series, designed to withstand harsh operating conditions and improve visibility for tractors and other machinery. At Partao, you can find a comprehensive selection of Hella spare parts, including Work Lights, Other Lighting, Air Filters, Alternators, and Apparel. These components are crucial for maintaining the functionality and safety of agricultural vehicles. Over 66,957 genuine Hella spare parts are available at Partao. Agricultural operators worldwide rely on Hella products for their durability, performance, and compliance with international standards. The brand's commitment to quality ensures that its lighting and electronic systems provide reliable operation, enhancing productivity and safety for machinery used in demanding farming environments across various regions.

Brand
Signal
High Tone
Voltage
12 V
Diameter
90 mm
Sound Level
113 dB(A)
Assembly Note
Assembly by qualified personnel required
Mounting Type
Flat Plug-in Connector
Housing Colour
Red/black
Frequency Range
415 Hz
Power Consumption
42 W
Registration Type
ECE
Supplementary Info
With E quality seal
Fulfils ECE Standard
R28
Temperature Range To
+90 °C
Temperature Range From
-40 °C
Protection Type IP Code
IPX9K
EAN
4082300298352
Manufacturer
HELLA
