Name: Helukabel - FLEXYOZ21 - PVC Flex Cable 2x1mm
Brand: Helukabel
SKU: helukabel-flexyoz21
Price: 2.87 EUR
Availability: InStock

Brand

Helukabel

Unit

Metre

Screen

No

Technical info

Approval Certificates VDE Reg N° 7691 Application In dry and moist rooms for light mechanical stresses. Outdoors only when protected. Not in water. As supply and interconnecting cable for measuring, controlling and regulating acc. to DIN VDE 0113. For computer units, control equipments on machine tools assembly lines, conveyors and production lines for controlling, regulating and monotoring work processes, industrial plants and production lines when temporarily freely moved and no periodic recurrence without forced guidance. Cross sections above 10 mm² are energy supply cable for fixed installations on machine tools in production lines. Design Conductor Copper bare stranded, VDE 0295 Class 5 Insulation PVC Type YI 2 (Polyvinyl chloride) Outer sheath PVC Type YM 2 (Polyvinyl chloride), colour grey, Core identification according to DIN VDE 0293:1990-01 JZ/OZ: black, white printed numbers and with/or without green/yellow core JB: coloured cores according to HD 308 S2

Number of cores

2

Outside diameter

5,6 mm

Nominal voltage U

500 V

Core cross section

1 mm²

Nominal voltage U0

300 V

Torsion resistance

No

Outer sheath colour

Grey

Supspension element

Yes

Content in sale unit

1 pcs

Protective conductor

No

Outer sheath material

PVC

Manufacturer Product ID

10060

Core identification type

Numbers

Core insultation material

PVC

Conductor category class code

5

Low smoke according to EN 61034-2

No

Working ambient temperature range

-15-80

Assembling ambient temperature range

-40-80 °C

Halogen free according to EN 50267-2-2

No

Oil resistance acccording to EN 60811-404

No

Flame retardant according to IEC/EN 60332-1-2

Yes

Fire reaction class code according to EN 13501-6

Eca

Low temperature resistance according to EN 60811 (504, 505, 506)

No

Min. permitted bending radius - moving application (free movement)

42 mm

Permitted cable outer temperature after assembling without vibration

-40.0-80.0

Min. permitted bending radius - stationare application (permanent installation)

23 mm

Manufacturer

Helukabel
