INA FAG - AY15NPPB - AY 15 NPPB Locking Bearing

OEM Supplier

SKU: ina-fag-ay15nppb

INA FAG - AY15NPPB - AY 15 NPPB Locking Bearing

€17.26

(excl. VAT)

In stock - ready to ship

Ships within 48 hours
Free shipping on orders over €60

Pay Securely with

Price

(Excl. VAT)

€17.26

The INA-FAG AY15NPPB is a high-quality insert bearing featuring a 15mm bore diameter and a 47mm outer diameter. Designed with an eccentric locking collar for secure shaft attachment and a spherical outer ring, this locking bearing ensures reliable rotational support. It includes RSR seals on both sides for enhanced protection, making it suitable for various agricultural, construction, and industrial machinery applications.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
ay15nppb
Unit
Each
Weight
0,09 kg
Properties
One-sided extended inner ring with 2 adjusting screws Convex outer ring without lubricating holes P seal Polyamide housing
Inner ring width
22 mm
dInside diameter
15 mm
Application range
Mobile mechanical engineering Stationary mechanical engineering
BOuter ring width
12 mm
DOutside diameter
40 mm
SWWrench/Spanner size
2.5 mm
Basic radial load static
4750 N
Basic radial load dynamic
10100 N
Ball centre to end distance
6 mm
Outside diameter of inner ring
23,9 mm
Locking screw centre to end distance
4 mm
EAN
4012802806861
Manufacturer
INA/FAG
