INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit
INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit
INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit
INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit
INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit

In stock - ready to ship

Order now for delivery between 11 May and 14 May
Free shipping on orders over €60

Pay Securely with

INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit

INA FAG - RA15XL - Sheet Steel Flanged Bearing Unit

€22.06

(Excl. VAT)

Price

(Excl. VAT)

€22.06

Product Description

The INA-FAG RA15-XL is a high-quality 15mm sheet steel flanged bearing unit, featuring a 2-bolt design and an eccentric locking collar for secure shaft attachment. This robust unit is engineered for reliable performance in various industrial and agricultural machinery applications. It has a 15mm bore, 64mm bolt hole centers, and an overall height of 28.6mm, weighing approximately 0.12kg. This unit is part of the INA Y-bearing series, known for its durability and ease of installation.
INA FAG
Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,176 genuine Ina-fag spare parts.

Product Details

Brand
INA/FAG
Unit
Each
Weight
0,23 kg
Properties
Housing components rust-resistant through Corrotect N coating Inner bearing has one-sided extended inner ring with clamp ring No subsequent lubrication possible Up to and including bearing block RA35: 3 attachment openings RA40 and above: 4 attachment openings
Consists of
2 halves of housing Clamp bearing Clamp ring
Total width
28,6 mm
Housing type
Round flange
Total height
24 mm
Housing width
81 mm
Housing height
7 mm
Bearing material
Steel
Flange thickness
2 mm
Housing material
Steel
Basic radial load static
4750 N
KMounting holes diameter
7,1 mm
dBearing inside diameter
15 mm
Basic radial load dynamic
10100 N
L*Bearing inner ring width
28,6 mm
Mounting holes/bolts circle diameter
63,5 mm
Manufacturer
INA/FAG
