INA FAG - RME90 - Housing Unit
INA FAG - RME90 - Housing Unit
INA FAG - RME90 - Housing Unit
INA FAG - RME90 - Housing Unit
INA FAG - RME90 - Housing Unit
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

INA FAG - RME90 - Housing Unit

INA FAG - RME90 - Housing Unit

€518.15

(Excl. VAT)

Price

(Excl. VAT)

€518.15

INA FAG
Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,174 genuine Ina-fag spare parts.

Product Details

Brand
INA/FAG
Unit
Each
Weight
8,45 kg
Benefits
Precise axis alignment possible Fixing points are relieved
Properties
Inner bearing has extended inner ring with clamp ring on both sides Can be subsequently lubricated
Consists of
• Bearing block Clamp ring
Total width
69,5 mm
Housing type
Round flange
Total height
50,5 mm
Housing width
265 mm
THousing height
32 mm
Bearing material
Steel
CFlange thickness
20 mm
ZFitting edge diameter
190 mm
Basic radial load static
79000 N
KMounting holes diameter
23 mm
dBearing inside diameter
90 mm
Basic radial load dynamic
109000 N
LBearing inner ring width
69,5 mm
Grease nipple thread diameter
M6
Locking ring outside diameter
118 mm
Manufacturer
INA/FAG
