Kramp - D4580600GK - Cylinder D45-80-600 GK-Series
Kramp - D4580600GK - Cylinder D45-80-600 GK-Series
Kramp - D4580600GK - Cylinder D45-80-600 GK-Series
Kramp - D4580600GK - Cylinder D45-80-600 GK-Series

In stock - ready to ship

Order now for delivery between 20 May and 23 May
Free shipping

Pay Securely with

Kramp - D4580600GK - Cylinder D45-80-600 GK-Series

Kramp - D4580600GK - Cylinder D45-80-600 GK-Series

€196.58

(Excl. VAT)

Price

(Excl. VAT)

€196.58

Product Description

Fully mounted With attachments Unique, innovative design Special circlip on piston
Kramp
Kramp is a leading distributor of spare parts and accessories for agricultural machinery. Their catalog includes wear parts, belts, and maintenance items for tractors and implements. Kramp ensures quick availability of critical components for farming operations. Shop more than 86,606 genuine Kramp spare parts.

Product Details

Brand
Kramp
Type
Double acting
Unit
Each
AStroke
600 mm
Benefits
Ready to use Simple assembly and disassembly Long service life High level of operational reliability
Properties
Pre-sprayed with primer Reusable mechanical cylinder head lock Maximum radial load: 10% of the axial force Maximum operating pressure depends on the maximum buckling load The maximum buckling load can be found using the cylinder software
Min. length
894 mm
Rod diameter
45 mm
Rod material
Steel 20MnV6
Technical info
Interchangeable with other brands Medium: mineral oil, HLP ISO VG 32 to ISO VG 46 Purity of the medium : ISO 4406 22/20/17 or NAS 9
Inside diameter
80 mm
Piston diameter
80 mm
Nominal pressure
200 BAR
Cylinder material
Steel ST52
Head nut material
Cast iron
Max. piston speed
0,1 m/s
Application category
Universal
Max. working pressure
250 BAR
Rod surface roughness
0,2 µm
Rod surface treatment
Chromated
DOil connection length
18 mm
Oil connection material
Steel
Max. working temperature
85 °C
Min. working temperature
-25 °C
IOil connections distance
648,5 mm
BMin. mounting holes distance
894 mm
Mounting type - rod connection
Bearing
COil connection inside diameter
28 mm
GMounting bush outside diameter
92 mm
Mounting type - cylinder connection
Bearing
Mounting thread type - rod connection
BSP
Cylinder material tolerance class code
H10
FCylinder end to mounting bush distance
15 mm
NMounting hole diameter - rod connection
40 mm
Mounting thread diameter - rod connection
1/2 Inch
MMounting hole center to head end distance
69 mm
Mounting diameter (width) - rod connection
40 mm
HMounting hole diameter - cylinder connection
40 mm
Mounting diameter (width) - cylinder connection
40 mm
Manufacturer
