Kramp - EPL20100ST - Cylinder EPL20-100 ST-Series

OEM Quality

SKU: kramp-epl20100st

Kramp - EPL20100ST - Cylinder EPL20-100 ST-Series

€50.54

(excl. VAT)

In stock - ready to ship

Ships within 58 hours
Free shipping on orders over €60

Pay Securely with

Price

(Excl. VAT)

€50.54

Fully mounted Unique, innovative design Special circlip on piston All methods of mounting possible Pre-sprayed with primer Maximum radial load: 10% of the axial force Maximum operating pressure depends on the maximum buckling load The maximum buckling load can be found using the cylinder software
Kramp
Kramp is a leading distributor of spare parts and accessories for agricultural machinery. Their catalog includes wear parts, belts, and maintenance items for tractors and implements. Kramp ensures quick availability of critical components for farming operations. Shop more than 86,634 genuine Kramp spare parts.

Brand
Kramp
Part Numbers
epl20100st
Pros
Ready to use Long service life High level of operational reliability
Type
Single acting
Unit
Each
Series
EPL-ST
AStroke
100 mm
Min. length
178 mm
Rod diameter
20 mm
Rod material
Chrome
Product details
Fully mounted Unique, innovative design Special circlip on piston All methods of mounting possible Pre-sprayed with primer Maximum radial load: 10% of the axial force Maximum operating pressure depends on the maximum buckling load The maximum buckling load can be found using the cylinder software
Cylinder material
Steel ST52
DOutside diameter
40 mm
Head nut material
Cast iron
Guide ring material
Plastic
Application category
Universal
Max. working pressure
250 BAR
Rod surface treatment
Chromated
Mounting type - rod connection
Bore
ECylinder head outside diameter
50 mm
Mounting type - cylinder connection
Bore
Cylinder material tolerance class code
H10
FMounting hole diameter - rod connection
10,2 mm
HMounting hole center to head end distance
15 mm
Mounting diameter (width) - rod connection
10,2 mm
GMounting holes distance - cylinder connection
26 mm
Mounting thread diameter - cylinder connection
1/4 Inch
Mounting diameter (width) - cylinder connection
10,2 mm
EAN
5700038824122
Manufacturer
Kramp
