Kramp-is1072 - Starter 12V, 3.2kW, 11-teeth, CW, Mahle
Kramp-is1072 - Starter 12V, 3.2kW, 11-teeth, CW, Mahle

Last known price:

€300.03

Get an up-to-date price and availability

Request a Quote

Pay Securely with

Kramp-is1072 - Starter 12V, 3.2kW, 11-teeth, CW, Mahle

Kramp-is1072 - Starter 12V, 3.2kW, 11-teeth, CW, Mahle

Last known price:

€300.03

Request a Quote

Product Description

The Kramp IS1072 starter motor is a robust 12V, 3.2kW unit designed for reliable engine starting in a wide range of agricultural machinery. It features an 11-tooth pinion with clockwise (CW) rotation, a flange diameter of 89mm, and a pinion diameter of 35mm. The starter is equipped with 3 mounting holes, each 11mm in diameter, with a center-to-center distance of 105mm between the mounting holes. With an overall length of 250mm and a weight of approximately 5.8kg, this starter is a direct replacement for various Case IH, New Holland, and Fiat tractor models, cross-referencing to several OEM part numbers including Mahle MS420.
Kramp
Kramp Groep, founded in 1951 by Johan Kramp in Varsseveld, Netherlands, is a leading European wholesaler of spare parts and accessories for the agricultural, forestry, and garden sectors. Headquartered in Varsseveld, the company has grown significantly over the decades, establishing a vast distribution network across Europe. Kramp offers an extensive and diverse product range, serving as a one-stop shop for dealers and workshops. Their catalog includes parts for tractors, implements, and various agricultural machines, encompassing everything from hydraulic components and engine parts to lighting and workshop supplies. The company focuses on providing high availability and efficient logistics to support its customers. At Partao, you can find a wide array of genuine Kramp spare parts. Our catalog includes Other Electrical Components, V-Belts, Other Merchandise & Gifts, Other Wear Parts, and Hoses & Fittings. Over 86,639 genuine Kramp spare parts are available at Partao. Kramp's strength lies in its comprehensive product offering and efficient supply chain, making it a crucial partner for agricultural businesses throughout Europe. The company's commitment to fast delivery and broad product availability helps farmers and mechanics maintain their machinery with minimal downtime, ensuring operations run smoothly.

Product Details

Brand
Mahle
Part Numbers
is1072
Equivalent OEM Part Numbers

Case Ih

19024002

Fiat

47120747

New Holland

4712074784276935

Mahle

MS420
Fits

Case Ih

JX100UJX1060CJX1070CJX1070NJX1075CJX1075NJX1080UJX1085CJX1090UJX1095CJX1095NJX1100UJX55JX60JX65JX70JX75JX80JX85JX90JX95MXM120MXM130MXM140MXM155MXM175MXM190

New Holland

TL100TL100ATL70TL70ATL80TL80ATL90TL90ATM120TM130TM140TM155TM175TM190TN55TN55DTN55STN60ATN60DATN60SATN65TN65DTN65FTN65STN65VTN70TN70ATN70DATN70FTN70NATN70SATN75TN75ATN75DTN75DATN75FTN75FATN75NATN75STN75SATN75VTN80FTN85FATN90FTN95FTN95FATN95NATN95VA

Fiat

L60L65L75L85L95
Voltage (V)
12
Power (kW)
3.2
Number Of Teeth
11
Rotation
clockwise
Flange Diameter (mm)
89
Pinion Diameter (mm)
35
Number Of Mounting Holes
3
Mounting Hole Diameter (mm)
11
Distance Between Mounting Holes (mm)
105
Length (mm)
250
Weight (kg)
5.8
Quality
OEM Quality
Manufacturer
Mahle
