Linak - LA2850024 - Linak Actuator 24V Stroke =500
Linak - LA2850024 - Linak Actuator 24V Stroke =500
Linak - LA2850024 - Linak Actuator 24V Stroke =500
Linak - LA2850024 - Linak Actuator 24V Stroke =500
Linak - LA2850024 - Linak Actuator 24V Stroke =500
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Linak - LA2850024 - Linak Actuator 24V Stroke =500

Linak - LA2850024 - Linak Actuator 24V Stroke =500

€340.91

(Excl. VAT)

Price

(Excl. VAT)

€340.91

Product Description

Consists of an impact-resistant plastic housing With a 2.3m cable with a 6.3mm jack Increased self-locking capability for LA28 actuators with a 6 or 9mm pitch Compatible with LINAK control boxes Offers protection class IP51 Ambient temperature from +5°C to +40°C Load cycle maximum 10% or two minutes and 18 minutes rest
Linak
Linak produces electric linear actuators and control systems for agricultural machinery, including tractor attachments and adjustable implements. The brand’s solutions enhance automation in tasks like bale handling and livestock feeding systems. Its products are recognized for reliability and integration with smart farming technologies. Shop more than 111 genuine Linak spare parts.

Product Details

Brand
LINAK
Equivalent AM Part Numbers

Linak

LA2850024
Pros
Easy installation Quiet operation
Unit
Each
Colour
Black
Stroke
500 mm
Voltage
24 V
Duty cycle
10 %
Cable length
2300 mm
Eye diameter
10,1 mm
On load speed
8,4 mm/s
Non load speed
10,8 mm/s
Max. pull force
2000 N
Max. push force
2000 N
Product details
Consists of an impact-resistant plastic housing With a 2.3m cable with a 6.3mm jack Increased self-locking capability for LA28 actuators with a 6 or 9mm pitch Compatible with LINAK control boxes Offers protection class IP51 Ambient temperature from +5°C to +40°C Load cycle maximum 10% or two minutes and 18 minutes rest
Insulation class
X5
Long description
The LA28 linear actuator is a powerful, low-noise and smooth-running actuator ideally suited for many applications in agriculture, industrial automation or healthcare.
Operating temperature
5-40 °C
Distance of mounting points
660 mm
Manufacturer
LINAK
