LINAK - LA3630012 - Actuator 12V S=300
LINAK - LA3630012 - Actuator 12V S=300
LINAK - LA3630012 - Actuator 12V S=300
LINAK - LA3630012 - Actuator 12V S=300

In stock - ready to ship

Ships within 48 hours
Free shipping

Pay Securely with

LINAK - LA3630012 - Actuator 12V S=300

LINAK - LA3630012 - Actuator 12V S=300

€801.99

(Excl. VAT)

Price

(Excl. VAT)

€801.99

Product Description

Built-in endstop switches Mechanical overload protection through integrated slip clutch Nonrotating piston rod eye Hand crank for manual operation Stroke length from 100 to 999mm Thrust from 500 N - 6.800 N depending on gear ratio and spindle pitch Max. speed up to 160mm/sec. depending on load and spindle pitch Heavy duty aluminum housing for harsh conditions Exchangeable cables in different lengths Ambient operating temperature -30°C to +65°C
Linak
Linak is a Danish company globally recognized as a leading manufacturer of electric linear actuator systems. Founded in 1907 by Christian Jensen, the company initially produced agricultural machinery. However, it was in 1976, under the leadership of Bent Jensen, that Linak shifted its focus to electric linear actuators, a move that defined its modern identity. Headquartered in Nordborg, Denmark, Linak remains a privately owned company. The brand's core expertise lies in developing and manufacturing innovative electric linear actuators, control systems, and related accessories. These solutions are crucial for creating movement in various applications, including healthcare, office furniture, industrial automation, and agricultural machinery. Linak actuators are known for their precision, reliability, and ability to integrate into complex systems, enabling automation and ergonomic adjustments in equipment like tractor attachments, adjustable implements, and livestock feeding systems. Partao offers a specialized range of Linak spare parts, including Control Consoles, Control Modules, Hydraulic Cylinders, Other Electrical Components, and Other Hydraulics Parts. Over 111 genuine Linak spare parts are available at Partao. Manufacturers and operators in the agricultural sector value Linak components for their contribution to smart farming technologies and enhanced operational efficiency. The brand's commitment to robust and intelligent actuator solutions ensures that machinery equipped with its systems benefits from precise control and reliable performance, even in demanding farm environments.

Product Details

Brand
LINAK
Pros
Maintenance-free and has a long service life A very strong alternative to hydraulic solutions High IP degree IP66 (dynamic) and IP69K (static) Extremely powerful
Unit
Each
Colour
Grey
Stroke
300 mm
Current
21 A
Voltage
12 V
Duty cycle
20 %
Eye diameter
12,2 mm
On load speed
11,9 mm/s
Non load speed
15,5 mm/s
Max. pull force
6800 N
Max. push force
6800 N
Insulation class
66 69
Operating temperature
5-40 °C
Distance of mounting points
500 mm
Manufacturer
LINAK
