Mac Power - GIHNK40LO - Rod End
Mac Power - GIHNK40LO - Rod End
Mac Power - GIHNK40LO - Rod End
Mac Power - GIHNK40LO - Rod End

In stock - ready to ship

Order now for delivery between 9 May and 13 May
Free shipping on orders over €60

Pay Securely with

Mac Power - GIHNK40LO - Rod End

Mac Power - GIHNK40LO - Rod End

€29.37

(Excl. VAT)

Price

(Excl. VAT)

€29.37

Product Details

Brand
Mac Power
D
62 mm
C1
32 mm
D1
46 mm
D2
89 mm
b.
4 °
Type
Female thread
Unit
Each
Thread
M33x2
D2Width
90 mm
Diameter
5.000 mm
L4Length
146 mm
Properties
Requires maintenance Lubricated connection steel/steel With 2 DIN912-10.9 screws for fastening Fine screw thread for normal cylinders
L7Length L7
41 mm
D5Width basis
80 mm
Hole diameter
40 mm
C1Height house
33 mm
D4Height basis
47 mm
ßEdge degrees
4 °
L3Thread length
46 mm
Thread direction
Right
dInside diameter
40 mm
Application range
Agricultural machines Cylinder Articulated points Suspension
BHeight inner ring
40 mm
DOutside diameter bearing
62 mm
D1Outside diameter innerring
46 mm
H1Distance basis center shaft
97 mm
Manufacturer
Mac Power
