Maintenance & Wear Parts

Mac Power - GIL10DO - Rod Head

Mac Power - GIL10DO - Rod Head

Mac Power - GIL10DO - Rod Head

Mac Power - GIL10DO - Rod Head

Number of products

In stock - ready to ship

Order now for delivery between 18 May and 21 May

Free shipping on orders over €60

Pay Securely with

Mac Power - GIL10DO - Rod Head

Mac Power - GIL10DO - Rod Head

€6.15

(Excl. VAT)

Price

(Excl. VAT)

€6.15

Number of products

Product Details

Brand

Unit

Each

Width

29 mm

Length

57.5 mm

Thread

M10 mm

Length L5

6,5 mm

Length L7

15 mm

Properties

Requires maintenance Lubricated connection steel/steel

Consists of

Rod head Radial spherical plain bearing

Diameter D4

15 mm

Edge degrees

12 °

Height house

7 mm

D5Diameter D5

19 mm

Thread length

20 mm

Inside diameter

10 mm

Height inner ring

9 mm

Outside diameter basis

17 mm

Outside diameter bearing

19 mm

Outside diameter innerring

13.2 mm

Distance basis center shaft

43 mm

Manufacturer

Mac Power
